ACTIVE SENSOR-FLUSH URINAL
Standards
Warranty
299
SPECIFICATIONS
Recommended Use
Domestic, hotel and commercial
WARRANTY & CARE DETAILS
Vitreous China American Standard Active Urinal
Urinal
Dear Customer,
White
Colour
This is the warranty by Reece Pty. Ltd. relating to this product.
Please keep it together with your purchase receipt. In the unlikely event of
Concealed rear inlet DN20 and kee seal
Water Inlet
a query please contact your nearest Reece Plumbing Centre.
Plastic Trap is supplied with kee seal for push-in
Outlet
connection to DN50 waste pipe
Warranty
You have purchased a quality product from Reece Australia. This
Application
Inwall, suitable for minimum cavity wall thickness
product is covered by a twelve month warranty. This warranty
of 90mm, Induct, Ceiling
covers faults in the product construction, material and assembly. Faulty
Maximum 2000mm from urinal inlet
Flush Pipe Height
products will be repaired or exchanged free of charge. Faulty items be-
come our property.
Minimum 500mm from urinal inlet
This warranty does not include faults caused by:
Urinal Fixing
L shape brackets supplied
• Unsuitable or improper use
• Incorrect installation
Template
Included in packaging
• Installation or part installation by the purchaser or any person other
than a LICENSED PLUMBER or tradesman
Water Saving
WELS 6 star rating (0.8L/flush)
Sensor models
240V AC (transformer) or 6 V DC (battery pack)
Easy to Adjust
Push button flush volume adjustment based on
the dynamic supply pressure
Disclaimer:
Products in this speci cation manual must by regulation be installed by licensed and registered trade people. The manufacturer/dis-
tributor reserves the right to vary speci cations or delete models from their range without prior noti cation. Dimensions and set-outs
Easy to Install
Supplied complete with all mounting hardware
WMK
listed are correct at time of publication however the manufacturer/distributor takes no responsibility for printing errors.
and cables
T21654.4
Tech Page Version 1
Sensor Technology
Prevents false detection
Normal Mode
In Normal mode the unit will flush after every use
Eco Mode Setting
Additional water conservation for high traffic
bathrooms. A flush is only activated after the
third user has visited or 15 minutes has elapsed,
whichever comes first.
Saver Mode
When high frequency usage is detected in
Normal mode, the unit will switch to Saver mode
to conserve water.
Urinal automatically flushes touch free after use.
Hygienic
Triggers and automatic hygiene flush after 48
Janitors Flush
hours of non-use.
Over-flow Protection
Sensor can detect blockages and will stop
flushing to prevent urinal overflow
Fault finding
Self diagnostic fault finding
Technical Support
If you have any questions or queries during
installation please contact Tech-Support for
phone assistance free call 07 3875 2465 We are
happy to assist you.
The more
stars the more
water efficient
WATER RATING
www.waterrating.gov.au
0.8
litres per
flush per stall
Disclaimer: Products in this specification manual must by regulation be installed by licensed and registered
trade people. The manufacturer/distributor reserves the right to vary specifications or delete models from
their range without prior notification. Dimensions are nominal measurements only. Dimensions and set-outs
In accordance with AS/NZS 6400
listed are correct at time of publication however the manufacturer/distributor takes no responsibility for
Licence No. 0025
printing errors.
Reece Limited
Tech Page Version 4
To wall with L shape bracket supplied
Including in packaging
3 Star rating, average ush 1.2 litres
WMKT21654.4
AS/NZS 6400:2005
12 months warranty (see below)
571
269
350
279
• Normal wear and tear
• Inadequate or complete lack of maintenance
Cleaning Recommendations
Any sanitaryware should not be cleaned with abrasive materials
eg. steel wool/scourers. Do not use any corrosive or abrasive cleaning
agents containing acids or scouring agents.
In the event of a warranty claim, we will replace or repair defective prod-
ucts, or pay for the cost of having defective products repaire
or replaced, but will not be liable for any injury to any person, damage to
any property, any indirect or consequential loss, or in any other respect.
To see the complete HIDEAWAY range go to
www.reece.com.au/bathrooms
page 1 of 16
Φ10
33
d
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Reece HIDEAWAY
Summary of Contents for Reece HIDEAWAY
- Page 1 • Normal wear and tear White Colour This is the warranty by Reece Pty. Ltd. relating to this product. • Inadequate or complete lack of maintenance Please keep it together with your purchase receipt. In the unlikely event of Concealed rear inlet DN20 and kee seal Water Inlet a query please contact your nearest Reece Plumbing Centre.
-
Page 2: Installation Instructions
2 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL INSTALLATION INSTRUCTIONS Check contents of packaged unit: Flush control unit is fitted with short 100mm cables for sensor and power and 1500mm long cable for solenoid flush valve connection Solenoid valve is fitted with 200mm cable and 2 pin connector (Fig. -
Page 3: Control Unit Connection
3 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL Rough in wall preparation: Note: All plumbing installation work has to be carried out in accordance with AS/NZS 3500. Installation requirements may vary, please check with your local authority. - Page 4 4 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL Urinal Installation Instructions: Cut out paper template supplied, place in position flat on wall aligning centre of cut out holes with inlet and outlet. Mark hole centres through template onto wall to provide wall locations for two ‘L’ shaped brackets (Fig. 5).
- Page 5 5 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL Important! Do not seal the urinal to the wall yet. Urinal should only be sealed once urinal has been fully commissioned. Fig. 9 Fig. 8 Commissioning: If you experience any technical issues refer to the Trouble Shooting Guide first (Section 12.0). If the issue cannot be resolved, contact Tech-Support for phone assistance on free call 07 3875 2465.
- Page 6 6 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL LED FLASH RESPONSE – FIRST TIME POWER ON MEANING Initial 2 short flashes followed by a sequence of double Self-check has detected a fault with the sensor. Please switch off the flashes in 3 second intervals.
- Page 7 7 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL To select a different flush program A new controller is supplied with the flush program set to Program 1. This is the normal flush mode and is the recommended setting.
-
Page 8: Overflow Protection
8 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL Cleaning: Cleaning of the urinal is an important part of the regular maintenance. This should not just only involve the ceramic part of the urinal. Cleaning the trap and pipe connection at regular intervals is equally important. - Page 9 9 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL Installation Types: Use the following figures to provide installation guidance: Fig. 11 In-ceiling installation Fig 12 In-duct installation Fig 13 In-wall installation Fig. 11 Plumbers, please ensure a copy of the installation...
- Page 10 10 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL 8.0 Installation Types (Continued) Fig. 12 Plumbers, please ensure a copy of the installation instructions is left with the end user for future reference...
- Page 11 11 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL 8.0 Installation Types (Continued) Fig. 13...
- Page 12 ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL System Description and Technical Specification 0.8 litre Active Urinal with Hideaway Smart Demand Operation and Urine Sensing Device • The Sensor detects urine entering the urinal bowl and initiates a flush accordingly. •...
- Page 13 13 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL 10.0 Diagnostic Function: To assist in finding faults in the electronic components the controller is equipped with a diagnostic function. Follow the instructions below to activate this function.
-
Page 14: Troubleshooting Guide
14 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL HIDEAWAY ACTIVE SENSOR-FLUSH URINAL 11.0 Trouble Shooting Guide: If you experience any technical issues refer to the Trouble Shooting Guide first. If the issue cannot be resolved, contact Tech- Support for phone assistance on free call 07 3875 2465. We are happy to assist you. - Page 15 9503309 HIDEAWAY URINAL SOLENOID CARTRIDGE 9503310 HIDEAWAY URINAL SOLENOID BODY 9503311 HIDEAWAY URINAL AIR-BREAK 9503984 HIDEAWAY URINAL CONTROL BATTERY POW ERED (LESS BATTERY) 9503985 HIDEAWAY URINAL BATTERY 6V CR-P2 Plumbers, please ensure a copy of the installation instructions is left with the end user for future reference...
-
Page 16: Spare Parts
16 of 16 HIDEAWAY ACTIVE SENSOR-FLUSH URINAL SPARE PARTS Picture Reece Code Product Description Part Number 9503303 HIDEAWAY URINAL CONTROL UNIT 240V 200.030 9503304 HIDEAWAY URINAL SENSOR TRAP (NO SEALS) 200.031 9503305 HIDEAWAY URINAL 240V TRANSFORMER 200.032 9503306 HIDEAWAY URINAL SENSOR EXT CABLE (2.65M) 200.033 9503307 HIDEAWAY URINAL INLET & OUTLET SEAL 200.034 9503309 HIDEAWAY URINAL SOLENOID CARTRIDGE 200.036 9503310 HIDEAWAY URINAL SOLENOID BODY 200.037 9503311 HIDEAWAY URINAL AIR‐BREAK 200.038...
