AVTECH
AVTECH's Smoke Sensor w/Escape Light is a battery-
powered smoke detector with additional electronics that
allow it to interface with Room Alert as a switch sensor; you
may set up and receive alerts remotely when the switch
state changes to assist your IT staff in monitoring and
protecting your valuable IT equipment.
The Smoke Sensor monitors the air, and when smoke
reaches its sensing chamber, it alarms. This unit will not
sense gas, heat, or flame.
Smoke Sensor Package Contents
•
One (1) Smoke Sensor
•
One (1) 25' speaker cable
•
One (1) 9V alkaline battery
•
Two (2) mounting screws with two (2) plastic screw anchors
Smoke Sensor
Install Your Smoke Sensor
Do not use this sensor in hazardous (classified) locations or life safety applications.
Do not use this sensor as a substitute for a complete fire detection system.
Attach the Smoke Sensor directly to wallboard or flat wall or ceiling surface.
Do not attach the Smoke Sensor to an electrical junction box as this may impair the
sensor's operation.
Smoke Sensor w/Escape Light
Mounting
Bracket
Escape
Light
Temperature & Environment Monitoring... Made Easy!
Swing-out
Battery
Compartment
Test/Silence
Button
Advertisement
Table of Contents
Related Manuals for Avtech RMA-SS1-SEN
Summary of Contents for Avtech RMA-SS1-SEN
- Page 1 AVTECH Smoke Sensor w/Escape Light AVTECH’s Smoke Sensor w/Escape Light is a battery- powered smoke detector with additional electronics that allow it to interface with Room Alert as a switch sensor; you may set up and receive alerts remotely when the switch state changes to assist your IT staff in monitoring and protecting your valuable IT equipment.
- Page 2 Smoke Sensor (RMA-SS1-SEN) Before you begin: Read Avoid These Locations in this document for placement recommendations. Step 1: Attach the included Mounting Bracket to the ceiling (or wall). 1. Remove the mounting bracket from the Smoke Sensor base by holding the Smoke Sensor and twisting the mounting bracket clockwise (right).
- Page 3 Smoke Sensor (RMA-SS1-SEN) Step 5: Connect your Smoke Sensor to Room Alert. Do not connect the switch sensor inputs (dry contacts) on AVTECH products to any live circuit. Use only low-voltage 2-wire cable to connect switch sensor inputs. Your Smoke Sensor comes with one end of the 25' speaker cable already attached.
- Page 4 Smoke Sensor (RMA-SS1-SEN) • In very damp, humid or steamy areas, or directly near bathrooms with showers Keep units at least 10 feet (3 meters) away from showers, saunas, dishwashers, etc. • Where the temperatures are regularly below 40° F (4.4° C) or above 100° F (37.8°...
- Page 5 Smoke Sensor (RMA-SS1-SEN) turns on: • A loud, repeating horn pattern will sound: 3 beeps, pause, 3 beeps, pause, etc. • The Escape Light will turn on. • The LED on the Test/Silence Button will flash once every second. The sensor may continue to alarm for a few seconds after you release the Test/Silence button.
- Page 6 Smoke Sensor (RMA-SS1-SEN) The Silence Feature The Silence Feature can temporarily quiet an unwanted alarm for several minutes. To use this feature, press the Test/Silence button on the cover. The Escape Light will turn off and the LED will flash every 10 seconds (for up to 10 minutes) to remind you the alarm has been silenced.
- Page 7 Configure Your Switch Sensor Configure Your Switch Sensor Use Room Alert’s Built-In Web Interface Settings Sensors Navigate to in your Room Alert web interface. The options you see below will vary depending on your Room Alert model. 1. Scroll down to Switch Sensor Settings. 2.
