Avtech RMA-DTH-SEN Installation Note

AVTECH
AVTECH's Digital Temperature & Humidity Sensor
monitors ambient indoor temperature and humidity.
The 2" L x 3/8" diameter probe is small and light enough
to install almost anywhere with no special tools.
With an operating range of -40º to 185º Fahrenheit
(-40º to 85º Celsius) and 5% to 95% relative humidity
(RH), this "Plug and Play" sensor provides values
accurate to +/- 2° C and +/- 4.5% RH to your Room
Alert. Your Room Alert uses these readings to calculate
heat index so you'll always know what the "feels like"
temperature is.
Digital Temperature & Humidity Sensor
Package Contents
• One (1) Digital Temperature & Humidity Sensor with built-in RJ-11 cable
This sensor is available in 25', 50' and 100' lengths:
Length Digital Temperature & Humidity Sensor
25' RMA-DTH-SEN
50'
RMA-DTH50-SEN
100' RMA-DTH100-SEN
Install Your Digital Temperature & Humidity Sensor
Do not use this sensor in hazardous (classified) locations or life safety applications.
1. Locate the probe (the end with the blue cap) where you
wish to measure temperature and humidity. Shown here
is a Digital Temperature & Humidity Sensor placed on the
grill of an air conditioner to monitor cool air output.
2. If necessary to hold the probe in place, mount it with a
cable clip, Velcro or nylon tie.
3. Run the built-in 25' cable back to your Room Alert or Wireless Sensor Hub. Try to avoid
running it near large electromagnetic devices or fluorescent lights, which produce EMI
that can interfere with the sensor's readings.
4. Connect the sensor to a digital sensor port on your Room Alert
or Wireless Sensor Hub.
AVTECH Software, Inc.
Digital Temperature & Humidity Sensor
Temperature & Environment Monitoring... Made Easy! AVTECH.com
