- Page 1 Home Automation Kit For the Hunter-Pro and Captain 8 Alarm Systems Installation Guide Pima Electronic Systems Ltd.
- Page 2 Home Automation systems, which have been adjusted to these systems. The connection to the Home Automation system can be made in one of two ways: Directly, using the supplied cable, SA-232 converter and LCL-11A adaptor (ver. H). Via local network (LAN), using the net4pro-i network card Kit contents ...
- Page 3 Connect the Molex cable to the control panel’s SERIAL connector. 2. Open the LCL-11A box, by squeezing and removing its cover. 3. Remove the RJ-11 jack: Use the supplied keychain mini screwdriver and loosen the four screws of the terminal block.
- Page 4 Control Panel Figure 1. Direct connection diagram 6. Connect the LCL-11A’s serial cable to the home automation system. Connection can be made either directly with the 9 pin connector, or via the Serial-to-UBS adaptor. The adaptor’s driver are on the CD, that’s in its package.
- Page 5 Installation net4pro-i Control Panel Home Automation System Figure 2. Network connection diagram...
- Page 6 Home Automation Kit Programming the net4pro-i To program the net4pro-i, follow the next steps: The net4pro-i is based on Lantronix’s XPort device. To configure it, download and install the Device Installer software, from the following link: http://ltxfaq.custhelp.com/app/answers/detail/a_id/644 Device Installer Run the .
- Page 7 Programming the net4pro-i Network Configuration Network Click on the purple side bar. Use the following IP configuration Click Enter the following data: IP Address: the control panel’s address Subnet Mask, Default Gateway: obtain from the network manager 4. Click Serial Settings Channel 1 Serial Settings...
- Page 8 PIMA Electronic Systems Ltd. shall have no liability for any death, personal and/or bodily injury and/or damage to property or other loss whether direct, indirect, incidental, consequential or otherwise, based on a claim that the Product failed to function.
