About the U225-004-R
The U225-004-R 4-Port USB 2.0 Hub allows you to attach and link all of your USB
devices (up to 127) to your computer via the USB port. The U225-004-R supports all
three data transfer speeds: low-speed (1.5 Mbps), full-speed (12 Mbps) and high-speed
(480 Mbps).
