Tripp Lite U227-FT3-R Owner's Manual

saFety InstrUCtIOns
• Keep this equipment away from humidity
• Use of this equipment in life support applications where failure of this equipment
can reasonably be expected to cause the failure of the life support equipment or to
significantly affect its safety or effectiveness is not recommended. Do not use this
equipment in the presence of a flammable anesthetic mixture with air, oxygen or
nitrous oxide

Package Contents

• U227-FT3-R USB 2.0 Hub with File Transfer
• USB 5-Pin Mini-B to USB-A, Male to Male Cable
• Owner's Manual

system requirements

USB Hub – Windows 2000 / XP / Vista, Mac OS X v10.4 / v10.5 or higher
File Transfer – Windows 2000 / XP / Vista
Features
• 3-Port Hub for added USB 2.0 connectivity
• USB-to-USB File Transfer between PCs
• Plug and Play capability
• Over-current detection and protection
• Quickly and easily exchange photos, music, movies, applications and other files
between PCs

LeD status

• The LED illuminates when the file transfer cable is connected between computers
• The LED flashes when the file transfer function is in use

Warranty and Warranty registration

1-YEAR LIMITED WARRANTY
Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material
and workmanship for a period of 1 year from the date of initial purchase. If the product should prove defective in material or
workmanship within that period, Seller will repair or replace the product, in its sole discretion. Service under this Warranty can
only be obtained by your delivering or shipping the product (with all shipping or delivery charges prepaid) to: Tripp Lite;
1111 W. 35th Street; Chicago IL 60609; USA. Seller will pay return shipping charges. Call Tripp Lite Customer Service at
(773) 869-1234 before sending any equipment back for repair.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT,
MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY
EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED
WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES
ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied
warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may have other rights
which vary from jurisdiction to jurisdiction).
Tripp Lite; 1111 W. 35th Street; Chicago IL 60609; USA
WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe
for the use intended. Since individual applications are subject to great variation, the manufacturer makes no representation or
warranty as to the suitability or fitness of these devices for any specific application.
WARRANTY REGISTRATION
Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You'll be automatically
entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
FCC Conditions
This equipment has been tested and found to comply with Part 15 Class B of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received and include interference that may cause undesired operation.
CE Compliance
This equipment is in compliance with the requirements of the following regulations: EN 55 022: EMC Directive 2004/08/EC
(EN55022/EN55024)
WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy
new electrical and electronic equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste
Tripp Lite follows a policy of continuous improvement. Product specifications are subject to change without notice.
Made in China.
Owner's Manual
UsB 2.0 3-Port Hub with File transfer
Keep this User's Manual for future reference.
Model: U227-FT3-R
In the event of the following, have your equipment checked by a service technician:
• The equipment has been exposed to moisture
• The equipment has been dropped and damaged
• The equipment has obvious signs of damage
• The equipment has not been working well or you cannot get it to work according to
the Owner's Manual

Installation and Operation

The U227-FT3-R is a plug
and play device. Simply
connect the unit's USB
dongle to the USB port on
your PC or laptop and the
USB 2.0 Hub is ready to use.
After connecting the U227-
FT3-R, a pop-up message
will appear indicating the USB Hub has been connected. Connect up to 3 USB2.0
peripherals to use on your computer.
Note: The U227-FT3-R can only be used to transfer files between Windows 2000 / XP /
Vista computers.
To use the file transfer function, connect the U227-FT3-R to the PC or laptop you wish
to share files between using the included Mini-USB cable. A screen should pop up
asking you what action you wish to perform. Click on Run Easysuite.exe to execute the
installer program. Note: Windows Vista users will encounter a User Account Control
dialog box. Enter the Administrator password and click allow to start the installation.
The workstation will appear and separate into two parts, Remote Host and Local Host
(see below). If the workstation does not automatically appear, go into the My Computer
screen of both PCs and double-click the EasySuite icon.
Simply drag-and-drop the desired file from the Local Host to the Remote Host (or vice
versa) to transfer files between the two PCs (see below).
remote Host
Local Host
Note: This screen shot is from Windows Vista 32-bit and may vary between operating
systems.
In the event your USB device does not receive enough power, and optional external
power jack is provided for a user-supplied power cord. Specifications for the power jack
are 5V, 1A .
