Specifications

SYSTEM SPECIFICATIONS
Lower cut-off frequency, -6dB
Upper cut-off frequency, -6dB
Frequency response within ± 1.5 dB
Minimum delay from analogue input to acoustic
output
Maximum short-term sine wave output on axis in
half space, average 100 Hz to 3 kHz, at 1 m, using
PoE+ power
Maximum long-term RMS acoustic output in same
conditions with IEC-weighted noise, at 1 m using
PoE+ power (limited by driver unit protection circuit
and the PoE power supply being used)
Maximum peak acoustic output per unit in a
listening room with music material, at 1 m, using
PoE+ power
Self-generated noise level in free space, at 1 m on
the acoustical axis, A-weighted
Harmonic distortion at 85 dB SPL at 1 m on axis
frequency range 50 – 200 Hz
frequency range >200 Hz
Dispersion angle (degrees), horizontal
Dispersion angle (degrees), vertical
Bass driver
Treble driver
Weight
Height
Width
Depth
Maximum short-term output level is limited by the PoE technology being used and the
crest factor of the audio signal. The stated values are typical for music and speech
signals.
Maximum long-term output level can be further limited by loudspeaker system protection.
Genelec recommends using PoE+ whenever possible. Using lower-power PoE can limit
short-term maximum and long-term maximum, depending on the characteristics of the
signal being reproduced.
User selectable filters can be set to positive gain. Positive gain must be used with care as
it is possible to cause premature overload of the loudspeaker at specific frequencies.
14
≤ 45 Hz
> 39 kHz
58 Hz – 20 kHz
2.3 ms
≥ 104 dB SPL
≥ 96 dB SPL
> 107 dB SPL
≤ 5dB
< 2%
< 0.5%
120°
100°
130 mm (5 in) cone
19 mm (3/4 in) metal dome
5.1 kg
285 mm (11 in)
1/4
189 mm (7 in)
7/16
178 mm (7 in)
