Data sheet
Autonomy: from 18 à 32km depending on the battery
Max. speed (on flat area): 6km/h
Maximum speed (angled area 3%): 4km/h
Motor power : 250 W
Motor voltage: 24 V
Operating temperature: -25°C to +50°C
Theoretical consumption in a straight line: 5,9Wh/km
Theoretical consumption while driving: 22,5Wh/km
Total weight: 6,00kg (batterie 6Ah), 6,4kg (batterie 10Ah)
Note : these values have been measured with a passenger of 100kg. Autonomy and speed may vary depending on the use conditions.
Motor unit
•
Overall length: 375mm
•
Overall width: 150mm
•
Overall height: 349mm
•
Weight: 4,8kg (+0,7kg for the holder)
•
Wheel diameter: 8 inches (203mm)
Battery
•
Battery type: Lithium-ion
•
Nominal tensio : 24v
•
Minimum tension (discharged): 19v
•
Maximum tension (charged): 29,4v
•
Overall dimensions: length 12cm x width 11,3cm x height 11,3cm
•
Weight: 1,2kg for the battery 6Ah, 1,6kg for the battery 10Ah
Compatibility
•
Wheelchair with fixed rigid frame
o
Wheel diameter of the manual wheelchair : 24 inches (ETRTO 540mm)
o
Diameter of the camber bar : 23 to 33mm
o
Diameter of the bar under the base : 15 to 30mm
o
Interaxis between those 2 bars : 130 to 290mm
•
Wheelchair with foldable frame, standard cross-brace: from 33cm to 55cm seat width
•
Weight of the user : 150kg max
