Avtech TMP-SDT-SEN Installation Note

AVTECH
AVTECH's lineup of digital temperature sensors monitor temperature in a variety of
environments. With an operating range of -67º to 257º Fahrenheit (-55º to 125º Celsius),
these "Plug and Play" sensors provide temperature values accurate to +/- 2º C to your
Room Alert.
These sensors are available in 25', 50' and 100' lengths:
Length Digital Temperature
25'
TMP-SDT-SEN
50' TMP-DT50-SEN
100' TMP-DT100-SEN
Digital Temperature Sensor Package Contents
• One (1) Digital, Digital Outdoor or Digital Fluid Temperature Sensor with built-in RJ-11 cable
Digital Temperature Sensors
AVTECH's Digital Temperature Sensor monitors ambient indoor
temperature. The 2" L x 3/8" diameter sensor housing is small and
light-weight enough to install almost anywhere with no special tools.
AVTECH's Digital Outdoor Temperature Sensor monitors ambient
temperature outdoors and in other harsh environments. A flexible
silicone coating protects the temperature sensor from the elements,
allowing it to function in environments where a standard sensor
would not be advisable.
AVTECH's Digital Fluid Temperature Sensor
monitors the temperature of fluids in refrigerated
and other environments using a unique sensor
housing. The temperature sensor is sealed
in a tube filled with propylene glycol, a non-
conductive clear liquid with a low freezing/high
boiling point. The sensor returns the readings of
the propylene glycol so that you may measure
the consistent temperature held by the fluid
rather than the ups and downs of the air moving
around it.
Digital Outdoor Temperature
TMP-DOT-SEN
TMP-DOT50-SEN
TMP-DOT100-SEN
Temperature & Environment Monitoring... Made Easy!
RJ-11 cable
Silicone
Sealed cap
Temp probe
in silicone
Propylene
glycol
Digital Fluid Temperature
TMP-DFT-SEN
TMP-DFT50-SEN
TMP-DFT100-SEN
3"
1 1/8"
