AVTECH's Extreme Temperature Sensor monitors a wide range of
cold temperatures with a rugged thermocouple and
smart ID box that communicates readings
to your Room Alert analog sensor
(built-in or external). This reliable
sensor has a range of -328º F to
32º F (-200º C to 0º C), making
it perfect for your low temperature
threshold monitoring.
Extreme Temperature Sensor
Package Contents
• One (1) Extreme Temperature Sensor
• One (1) 10' thermocouple coil w/ 2" probe
• One (1) 18V power adapter
• One (1) 25' speaker wire
• Two (2) mounting screws
• One (1) Installation Note (You're reading it now.)
Extreme Temperature Sensor And Power Ports
Power
Adapter
Cord
Install Your Extreme Temperature Sensor
Do not use this sensor in hazardous (classified) locations or life safety applications.
Step 1: Locate the thermocouple and mount the sensor.
Your Extreme Temperature Sensor comes with a 10' thermocouple coil. When you are
considering the layout of your components, remember that the sensor housing is not designed
to withstand the same temperatures as the thermocouple.
AVTECH Software, Inc.
Extreme Temperature Sensor (RMA-ET1-SEN)
Left
Polarized
Speaker Wire
Copper
(+)
Silver
(-)
Temperature & Environment Monitoring... Made Easy!
10'
Thermocouple
Coil
2" Probe
Right
Installation Note
Sensor ID Box
Thermocouple
Coil
AVTECH.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avtech RMA-ET1-SEN
Summary of Contents for Avtech RMA-ET1-SEN
- Page 1 Extreme Temperature Sensor (RMA-ET1-SEN) Installation Note AVTECH’s Extreme Temperature Sensor monitors a wide range of cold temperatures with a rugged thermocouple and smart ID box that communicates readings to your Room Alert analog sensor (built-in or external). This reliable Thermocouple sensor has a range of -328º...
- Page 2 AVTECH.com or contact a Product Specialist. Do not connect the analog inputs on AVTECH products or other electrical appliances to live circuits of over 5 VDC. Use only low-voltage 2-wire cable to connect dry contacts. Step 3: Connect to a power source.
- Page 3 Extreme Temperature Sensor (RMA-ET1-SEN) Configure Your Extreme Temperature Sensor With Room Alert’s Built-In Web Interface Navigate to Settings Sensors in your Room Alert web interface. Scroll down to “Analog Sensor Settings” when using Room Alert models that have a built-in analog input port.
- Page 4 Your Room Alert will automatically reboot and commit your changes. With AVTECH’s Device ManageR Software For Advanced Functionality For advanced functionality and easy management of multiple units, configure your sensor with AVTECH’s Device ManageR, the software that comes FREE with the purchase of any Room Alert monitor.
- Page 5 Extreme Temperature Sensor (RMA-ET1-SEN) Extreme Temperature Sensor Features & Specifications Environment Condition Monitored ....Extreme-cold ambient temperatures Type Of Sensor ........... Analog Power Supply ............18V power adapter Included ............Yes Thermocouple Included ............Yes Length ............. 10' Operating Range ..........-328º F to 32º F (-200º C to 0º C) Steps Between Temperature Readings ....
