U-Line H-8041 Quick Start Manual

π
H-8041
COMPACT AUTO FLOOR SCRUBBER
NOTE: This guide is intended for quick reference
only and does not replace the instruction
manual. Before using this machine, read full
instruction manual included with machine
packaging.
NOTE: Battery must be fully charged before first
use. (See Instructions)
FILL TANK
1. Add water and detergent into the tank.
(See Figure 1)
Figure 1
NOTE: Use a non-foaming detergent with a
pH range between 7-11. Be sure to follow the
detergent instructions for proper dilution.
2. Open flow from detergent tank by pushing lever up
to horizontal position. Leave open. (See Figure 2)
Figure 2
BEGIN WORK
1. Lower squeegee by pushing handle down.
(See Figure 3)
Figure 3
PAGE 1 OF 3
1-800-295-5510
uline.com
OPERATION
2. Turn on unit and press brush button. All lights will light
up and unit is fully functional.
(See Figures 4 and 5)
Figure 4
3. After use, empty the recovery tank by using the
attached drain hose. (See Figure 6)
Figure 6
4. Once finished, charge the battery.
NOTE: The battery should be charged after
every use, and once every three weeks to
maintain battery life.
WHEN FINISHED CLEANING
1. Turn machine off by pressing the On/Off button for at
least four seconds.
2. Raise squeegee.
3. Close the detergent tap.
4. Empty the recovery tank (see Maintenance).
5. Charge the battery (see Maintenance).
Figure 5
0620 RH-8041
