- Page 1 ADJUSTABLE INCLINE MANUAL TREADMILL WITH ARM EXERCISERS USER MODEL NO.: T017 IMPORTANT! Read all instructions carefully before using this product. Save this manual for future reference. EXERCISE EQUIPMENT QUESTIONS: Contact customer service at service@zoovaa.com USER MANUAL...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS At Efitment your safety is our top priority and to make sure both you and the unit remain in perfect working order, we encourage you to read all the instructions before assembling and using your new Efitment machine. -
Page 3: Exploded Drawing
EXPLODED DRAWING... -
Page 4: Parts List
PARTS LIST Description Qty. Description Qty. Main Frame Computer Bottom Frame Plug Left Side Hand Post Plastic End Cap Right Side Hand Post Magnet Handlebar Running Board Base of the Magnet Running Belt Front Roller Tension Knob Front Axle 48L/R Moving Handlebar Rear Roller Incline Adjuster Rear Axle... -
Page 5: Hardware Package
HARDWARE PACKAGE... - Page 6 ASSEMBLY INSTRUCTIONS NOTE: The assembly parts list is included for your reference. Some parts are preassembled on the machine. In these instances, simply remove and reinstall the parts as required. STEP 1: Attach Left & Right Side Hand Posts (No. 3 & No. 4) to the Bottom Frame (No.
- Page 7 STEP 2: Before you assemble the tension cable, make sure that it is at level 8. HIGH assemble magnetic tension adjustment mechanism: 1. Insert tension wire into the gap in the Baffle Plate (No. R), then lower Steel Wire Cap (No. T) into the hole in Baffle Plate (No.
- Page 8 2. Pull Tension Sleeve (No. X) downward to bring Baffle Plate (No. R) close to Tension Permanent Seat (No. S), then insert Tension Bolt (No. V) into Tension Permanent Seat (No. S). 3. Turn Tension Nut (No. U) clockwise in order to tighten Tension Nut (No.
- Page 9 STEP 3: Cover Plastic Cover (No. 38) to the flywheels of the Main Frame (No. 1) with 4 Bolts (No. B) and 4 Washers (No. K), use Wrench (No. L) to tighten. STEP 4: Stabilize the Left & Right Side Hand Posts (No.
- Page 10 STEP 5: Attach the Handlebar (No. 5) to the Left & Right Side Hand Posts (No. 3 & No. 4) with 2 Bolts (No. C) and 2 Arc Washers (No. G), use Wrench (No. L) to tighten. Connect the Short Trunk Wire (No. 17b) and Long Trunk Wire (No.
- Page 11 STEP 7: The 4 Plastic Washers (No. Q) are bound with the 2 Plastic Swing Seats (No. 55). Cut the straps and remove 4 Plastic Washers (No. Q) from the 2 Plastic Swing Seats (No. 55). Attach the Moving Handlebars (No. 48L/R) with 4 Plastic Washers (No.
-
Page 12: Lubricating The Treadmill
LUBRICATING THE TREADMILL *IMPORTANT NOTE: You will need to lubricate your treadmill before the first use. Lubricating the Running Board (No.45) and Running Belt (No. 46) is essential as the friction between the two affects the life span and function of the treadmill. Inspect the Running Board (No. 45) and Running Belt (No. -
Page 13: Adjusting The Incline
ADJUSTING THE INCLINE There are 3 incline angles (A: 7°, B: 8°, C: 9°). To adjust the incline, lift the rear end of the main frame up, and use your other hand to adjust the incline adjuster to the desired position. NOTE: Always use proper lifting technique to prevent injury. -
Page 14: Adjusting The Belt
FOLDING Before folding, completely loosen Knob (No. J) from the bottom hole A in the Bottom Frame (No. 2). Lift Main Frame (No. 1) to the upright position, then insert and tighten Knob (No. J) to the upper hole B. ADJUSTING THE BELT If the Running Belt (No. -
Page 15: Adjusting The Tension
ADJUSTING THE TENSION The user can set the desired tension according to the picture showing: To decrease the tension, loose the Bolt (No. 20) counter-clockwise, turn the Bolt (No. 13) clockwise, then tighten the Bolt (No. 20) clockwise. To increase the tension, loose the Bolt (No. 20) clockwise, turn Bolt (No. - Page 16 ADJUSTING THE TENSION OF THE MOVING HANDLEBARS This treadmill has Moving Handlebars (No. 48L/R) that let you exercise your arms and upper body. Use the Moving Handlebars (No. 48L/R) as shown in the picture. You can exercise with just the Moving Handlebars (No.
-
Page 17: How To Move The Treadmill
HOW TO MOVE THE TREADMILL Before attempting to move the treadmill, please make sure that it has been properly folded. The Knob (No. J) must be tightened. Start by placing two hands at Hand Pulse Sensors (No. 25) to support the treadmill. Next, please place one foot at Plastic Wheel (No. - Page 18 OPERATING INSTRUCTIONS TIME………………………………………………….……........………………..….00:00-99:59 MIN SPEED…………………………………………………..............0.0-99.99 MPH DISTANCE……………………………………………….…...............0.0-999.9 MI CALORIE………………………………………………………............0.0-999.9 KCAL ODOMETER………………………………………………………………………………….…………………………….0-9999 MI PULSE…………………………………………………...............40-220 BPM The display will turn on when you start walking on the treadmill or when you press the button After 4-5 minutes of inactivity, the display will shut off automatically. When the treadmill is not moving, computer will display STOP on the side.
- Page 19 COUNTDOWN FUNCTION: Under STOP condition, press SET button to set Time, Distance or Calorie to countdown. Once the data goes to zero, the computer will beep. That means countdown function ends, and the data starts counting from “1”. You can set the Countdown function only when the treadmill is stopped.
