Possible Location Of Magnet On Bearing Housing - UE Systems Ultraprobe 10.000 Indentification And Operation

Rev. 1.0 3/2012 SAFETY: Wrist Strap to be worn at ALL TIMES
5 min UE Systems Training

Possible Location of Magnet on Bearing Housing,

side of Housing. Never on Fan Shrouds or Covers.
5
Possible Location of Magnet; Tip of Grease Gun,
when Bearing Housing Cannot be Reached.
7
Page 2 of 3
Ultrasound Ultraprobe 10,000 Instructions
Ultraprobe 201 Indentification and Operation
*Lubricate Slowly and Cautiously*
Possible Location of Magnet on Bearing Housing,
top of Housing. Never on Fan Shrouds or Covers.
6
While Lubing, Make Sure that the Display of the
'Grease Caddy can be Viewed, to note Decibel
8
Change of the bearing.
TQC Work Verify
