Rev. 1.0

3/2012 SAFETY: Wrist Strap to be worn at All Times

2 min

UE Systems Training

Adjust Sensitivity to obtain a Steady dB and 2-4

Bars on Intensity Meter

Press Enter to begin storage process of sound

WAV file (and text info, i.e. dB, Freq, etc)

Page 1 of 3

Ultrasound Ultraprobe 10,000 Instructions

*Compact Flash Card & Module Inserted BEFORE Turning ON*

Recording a Sound WAV

Push Sens Knob 2X to move cursor to Function

Bar/ Rotate Sens. Knob until "Press Enter for

Record WAV" appears

Push Sens Knob to begin recording. Unit should

be steady during recording.

TQC

Work

Verify

Table of Contents

Do you have a question about the Ultraprobe 10,000 and is the answer not in the manual?

Page 1 Ultrasound Ultraprobe 10,000 Instructions Recording a Sound WAV Rev. 1.0 3/2012 SAFETY: Wrist Strap to be worn at All Times Work Verify 2 min UE Systems Training Adjust Sensitivity to obtain a Steady dB and 2-4 Push Sens Knob 2X to move cursor to Function Bars on Intensity Meter Bar/ Rotate Sens.
Page 2 Ultrasound Ultraprobe 10,000 Instructions Recording a Sound WAV Rev. 1.0 3/2012 SAFETY: Wrist Strap to be worn at All Times Work Verify 2 min UE Systems Training Manual Record Time vs. Preset Record Time under "Recording Wav File" appears during recording of Setup Menu "Set Record Time"...
Page 3 Ultrasound Ultraprobe 10,000 Instructions Recording a Sound WAV Rev. 1.0 3/2012 SAFETY: Wrist Strap to be worn at All Times Work Verify 2 min UE Systems Training Display shows file writing to Flash Card. "Erase Two Different Screens appear for CONFIRMATION Data Flash,"...
