Page 1: Version
Version 1 ® ULTRAPROBE Instruction Manual... - Page 2 Version 1 Safety advisory Please read before using your instrument. Warning Improper use of your ultrasonic detector may result in death or serious injury. Observe all safety precautions. Do not attempt to make any repairs or adjustments while the equipment is operating. Be sure to turn off and LOCK OUT all electrical and mechanical sources before performing any corrective maintenance.
-
Page 3: Table Of Contents
Component assembly magnetic mount sensor ..............6 Basic components ....................... 6 Component Assembly Instructions................. 7 UE Systems Grease Caddy Docking Station Mounting Instructions ........7 UE Systems Grease Caddy Docking Station Mounting Instructions ........8 Metered Housing ......................9 Headphones ......................10 Using the Ultraprobe 201 Grease Caddy ................11... -
Page 4: Theory
Version 1 Theory Ultrasound consists of high frequency sound waves that are above the hearing limits of human perception. Generically ultrasonic frequencies are considered to start at 20,000 cycles per second ( 20 kilohertz or 20 kHz). Most ultrasonic instrumentation used for equipment condition analysis includes frequencies that range from 20 to 100 kHz. -
Page 5: Monitoring Bearing Wear
Version 1 Monitoring bearing wear In a bearing, normal bearing loads cause an elastic deformation of the elements in the contact area, which give a smooth elliptical stress distribution. But bearing surfaces are not perfectly smooth. For this reason, the actual stress distribution in the contact area will be affected by a random surface roughness. -
Page 6: Component Assembly Magnetic Mount Sensor
Version 1 Component assembly magnetic mount sensor Basic components Your kit consists of the following parts: A Grease Caddy Assembly B Clamp C Sensor Assembly – Magnetic Sensor and Cable with Acoustic Shield... -
Page 7: Component Assembly Instructions
Version 1 Component Assembly Instructions 1. Attach the Ultraprobe 201 Grease Caddy A to the grease gun, using Clamp B. 2. Connect cable from Sensor Assembly to input of Grease Caddy Before you begin testing, it is advisable to familiarize yourself with the basic components of your kit. -
Page 8: Ue Systems Grease Caddy Docking Station Mounting Instructions
Version 1 UE Systems Grease Caddy Docking Station Mounting Instructions Completed setup Close up view Ready to use Keep Magnetic on Docking Station when greasing NOTE: Do not use Docking Station when using rubber or plastic tubes. -
Page 9: Metered Housing
Version 1 Metered Housing The main component of the Ultraprobe 201 is the metered housing. From back to front, let‘s examine each part. On and OFF buttons. To turn the instrument ON, push the ON button in. Once pressed the instrument will stay on and then automatically turn off after 5 minutes (this will extend the battery charge and active use of the instrument). -
Page 10: Headphones
The standard headphone plugs into the “phone” jack. NOTE: Always use the headphones when operating the Ultraprobe 201 Grease Caddy. There may be times where stray signals influence the LED indicator. Using the headset will assure that the sounds being received are coming from the subject test bearing. -
Page 11: Using The Ultraprobe 201 Grease Caddy
Version 1 Using the Ultraprobe 201 Grease Caddy You may use your Ultraprobe 201 Grease Caddy to know when to lubricate by setting a baseline level. You may choose to lubricate whenever a bearing exceeds a pre-set baseline by 8 dB-12 dB accompanied by a uniform white noise or rushing sound. -
Page 12: Specifications Ultraprobe 201 (Grease Caddy)
Version 1 Specifications Ultraprobe 201 (Grease Caddy) Housing Attaches directly to the grease gun, gives visual and audible indication for proper lubrication Construction Aluminum housing Dimensions 13.3 x 6.7 x 4.5 cm (LWH) Operating Temperature 0 °C to 60 °C Relative 10-95% non-condensing at up to 30 °C... - Page 13 Version 1 Need further support? Want information regarding products or training? Contact : UE Systems Europe, Windmolen 22, 7609 NN Almelo (NL) info@uesystems.eu www.uesystems.eu t: +31 (0)548 659-011 f: : +31 (0)548 659 010 www.uesystems.eu...
