Rev. 1.0
3/2012 SAFETY: Wrist Strap to be worn at ALL TIMES
5 min
UE Systems Training
Identification of Parts of Ultraprobe 201 "Grease
Caddy."
1
10 LED that equal 3 dB Each. ON/OFF Bottons w/
5min auto off. 8 Position Sensitivity Selector with
3
'0' being highest sensitivity.
Page 1 of 3
Ultrasound Ultraprobe 10,000 Instructions
Ultraprobe 201 Indentification and Operation
*Lubricate Slowly and Cautiously*
The "Grease Caddy" can be attached to a Grease
Gun or Worn in a Holster w/Belt Clip.
2
To Calculate Decibel, count Number of LEDs '5'
multiply by 3 (=15). Add to Sensitivity Setting' 50'
4
(3 X 5 = 15 + 50 = 65 dB).
TQC
Work
Verify
