Single unit adjustable heavy-duty rack mount kit (7 pages)
Summary of Contents for Keithley 4299-2
Page 1
1-888-KEITHLEY www.keithley.com Introduction This instruction sheet contains a parts list and installation information for the Model 4299-2 Universal Dual Unit Heavy-Duty Rack Mount Kit. This kit includes all hardware necessary to specifically mount two Model 260x SourceMeter Instruments or 1 model 260x with most other Keithley or Agilent Half Rack Products in a standard ®...
Model 4299-2 Installation Instructions Installation The following procedure outlines the installation of the rack mount kit. WARNING Make sure the instrument that is being installed is in a powered down state with all cables unplugged. Failure to install an instrument in a discharged state may cause an electrical shock or death.
Page 3
Model 4299-2 Instructions Step 1. Prepare instrument To prepare the instrument for mounting, remove the handle, the mounting ears, and both rear feet. The following information outlines this process. 1. Remove the handle —The handle serves as an adjustable tilt-bail. Adjust its position by gently pulling it away from the sides of the instrument case and swinging it up or down.
Page 4
Model 4299-2 Installation Instructions Step 2. Install mounting hardware to instrument NOTE Install the mounting hardware on the rack rail side of each unit (not the same side as the other unit) (see 2). 1. Determine and select the unit’s side that is to be installed closest to the rack rail (see Note).
Page 5
2 Places on each(See Note**) (2602-333) Front Mounting Note: Holes used for the *Rear bracket used only with Keithley produdcts of 2100 DMM or the same length, excluding the 2100 DMM Agilent product **When installing a 2100 DMM or Agilent unit, use M4x12 screws in the front mounting holes;...
Page 6
Model 4299-2 Installation Instructions Step 3. Prepare the rack 1. Install Cage Nuts (FA-274) into rack holes to be aligned with the holes in the Rack Mount Extension Arms (2602-335) (refer to Figure 4). (The rack holes selected determine unit placement in rack.) 2.
Page 7
Model 4299-2 Instructions Step 4. Install Instruments NOTE Although the following step may be completed by one person, two are recommended. When rack mounting restricts access to the main power cord, provide a separate main power disconnect device. This device must be located in close proximity to the equipment and within easy reach of the operator.
Page 8
Model 4299-2 Installation Instructions Truss Head Screw (Phllips) 10-32x5/8PHTRSH (4 Places) Front Rack Rail (2 places) PA-909 Rev. C / May 2007...
