Introduction
This packing list contains the parts list and installation information for the Model 4288-4 Dual Fixed Rack Mounting Kit. The
Model 4288-4 includes all of the hardware necessary for side-by-side rack mounting of a 3
182, 428, 486, 487, 776, 2000, 2001, 2002, 2010, 2304, 2400, 2410, 2420, 7001) and a 5-inch high instrument (Models 195A,
196, 220, 224, 230, 263, 595, 614, 617, 705, 740, 775, etc.). The rack mounting kit can be installed in a standard 19-inch rack.
Parts list
Table 1 lists the parts supplied with a Model 4288-4 Dual Fixed Rack Mounting Kit.
Table 1. Model 4288-4 dual fixed rack mounting kit parts list
Qty.
1
2
1
1
1
1
1
Rear support brackets to chassis:
4
4
Rear support brackets and front panel to rails:
8
8
Clamps to chassis:
6
Spacer to chassis:
2
Model 4288-4 Dual Fixed Rack Mounting Kit
Description
Chassis
Bracket, rear support
Front panel
Clamp (for 3
inch instrument)
Clamp assembly (for 5-inch instrument)
Clamp (for 776 only)
Spacer (for all 3
inch products other than 2000, 2010, 2400,
and 776)
10-32 Kepnut
10-32 x
Phillips pan head screw
Fastener captive nut
10-32 x
Phillips pan head screw
8-32 x
Phillips pan head screw
Plastic fastener
inch high instrument (Models
Keithley
part no.
4288-4-301
BR-21
4288-4-303
4288-4-302
1019A-303
4288-4-305
4288-4-304
10-32KEPNUT
10-32x PPH
FA-148
10-32x PPH
8-32x PPH
FA-240
PA-385 Rev. C / 2-00
