Introduction

This instruction sheet contains a parts list and installation information for the Model 4299-3 Universal Single Unit
Rack Mount Kit. This kit includes all hardware necessary to mount one half-rack instrument (either Keithley, or
Agilent unit) excluding the 260x or other products that are designated to use the rear support feature in a standard
19-inch rack.

Parts list

Table 1 lists the parts supplied with the Model 4299-3 Single Unit Universal Rack Mount Kit4299-1 parts list
4266-1 parts list
Quantity
Description
1
Front Rack Ear
6
Cage Nut
1
"DO NOT DISCARD" Label
4
#8-32 X 3/8 LG Phillips Pan Head Screw
6
#10-32 X 5/8 LG Phillips Truss Head Screw
1
Half Rack Front Panel
4
M4X12 Phillips Pan Head Screw
PA-942 Rev. A / May 2007
Universal Single Unit Rack Mount Kit
Keithley Part Number
2602-333
FA-274
MC-345
8-32X3/8PPH
10-32X5/8PHTRSH
2602-344
M4X12PPH
Model 4299-3
1
