OPERATING INSTRUCTIONS
FP-DO-400
8-Channel, 5 to 30 V Discrete
Output Module
These operating instructions describe the installation, features, and
characteristics of the FP-DO-400. For details on configuring and
accessing the FP-DO-400 over a network, refer to the user manual
for the particular FieldPoint network module you are using with
the FP-DO-400.

Features

The FP-DO-400 is a FieldPoint discrete output module with the
following features:
Eight discrete output channels
Sourcing outputs supply 2 A per channel, 9 A
Compatible with voltages from 5 to 30 VDC
On/Off LED indicators
Hot plug and play operation
3,000 V input to output isolation
Double insulated for 250 V safe working voltage
–40 to +70 °C operation

Installation

The FP-DO-400 mounts on a FieldPoint terminal base (FP-TB-xx)
unit. The hot plug and play operation of the FP-DO-400 allows you
to install it onto a powered terminal base without disturbing the
operation of other modules or terminal bases. The FP-DO-400
receives operating power from the terminal base.
FieldPoint ™ is a trademark of National Instruments Corporation. Product and company names
mentioned herein are trademarks or trade names of their respective companies.
321681B-01
© Copyright 1997, 1999 National Instruments Corp. All rights reserved. June 1999
2
per module

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FieldPoint FP-DO-400 and is the answer not in the manual?

Questions and answers

Summary of Contents for NI FieldPoint FP-DO-400

  • Page 1 OPERATING INSTRUCTIONS FP-DO-400 8-Channel, 5 to 30 V Discrete Output Module These operating instructions describe the installation, features, and characteristics of the FP-DO-400. For details on configuring and accessing the FP-DO-400 over a network, refer to the user manual for the particular FieldPoint network module you are using with the FP-DO-400.
  • Page 2 To install the FP-DO-400, refer to Figure 1 and follow these steps: 1. Slide the terminal base key to either position X (used for any module) or position 4 (used for the FP-DO-400 module). 2. Align the FP-DO-400 alignment slots with the guide rails on the terminal base.
  • Page 3 – – Load Load Load Load a. Total Current Less b. Total Current Greater Than 5 Amps Than 5 Amps Figure 2. Basic Field Connections (Two Channels Shown) Table 1 lists the terminal assignments for the signals of each channel. Table 1.
  • Page 4 Discrete Output Circuit The discrete outputs of the FP-DO-400 consist of optically- isolated sourcing outputs. In the ON state, a transistor is turned on between the positive external supply voltage (the V and V terminals) and the output (V ) terminal. In the OFF state, this transistor is turned off, allowing only a small leakage current to flow.
  • Page 5 Figure 3 shows the diagram of one channel’s discrete output circuit. Optical Isolation Load Figure 3. Discrete Output Circuit Status Indicators Figure 4 shows the module label and status indicators. You can remove the insertable label to see wiring diagrams for the input channels.
  • Page 6 Isolation and Safety Guidelines Caution Read the following information before attempting to connect any circuits which may contain hazardous voltages to the FP-DO-400. This section describes the isolation of the FP-DO-400 and its compliance with international safety standards. The outputs are isolated from the backplane provided by the terminal base with an optical isolation barrier designed and tested to provide protection against fault voltages of up to 3000 Vrms.
  • Page 7 Specifications These specifications are typical for the range –40 to +70 °C unless otherwise noted. Input Characteristics Number of channels......8 Voltage range ........5 to 30 VDC 10 to 30 V Voltage Range Output impedance ...... 0.3 Ohm (0.3 volts drop at 1 A) Maximum output current....
  • Page 8 Environment Operating temperature ...... –40 to +70 °C Storage temperature ......–55 to +100 °C Relative humidity......5% to 90% non-condensing CE Mark Compliance This product meets applicable EU directive(s) as follows: Safety isolation ........ EN 61010 (double insulation for 250 Vrms working isolation, installation category II) EMC directive...
