Avaya Solution & Interoperability Test Lab
Application Notes for TAS FreiTel-IP Handsfree Telephone
with Avaya Communication Manager Avaya SIP
Enablement Services – Issue 1.0
These Application Notes describe the configuration of TAS FreiTel-IP handsfree telephone for
operation with Avaya Communication Manager. TAS FreiTel-IP is a SIP telephone intended
for use in environments where a handset and keypad are not required, such as elevators. These
Application Notes contain an extensive description of the configurations for both FreiTel-IP
and Avaya Communication Manager which were used for testing.
Information in these Application Notes has been obtained through compliance testing and
additional technical discussions. Testing was conducted via the DevConnect Program at the
Avaya Solution and Interoperability Test Lab.
MRR; Reviewed:
SPOC 12/13/2007
Abstract
Solution & Interoperability Test Lab Application Notes
©2007 Avaya Inc. All Rights Reserved.
1 of 23
FreiTel-SIP
Advertisement
Table of Contents
Related Manuals for Avaya TAS FreiTel-IP
Summary of Contents for Avaya TAS FreiTel-IP
- Page 1 Enablement Services – Issue 1.0 Abstract These Application Notes describe the configuration of TAS FreiTel-IP handsfree telephone for operation with Avaya Communication Manager. TAS FreiTel-IP is a SIP telephone intended for use in environments where a handset and keypad are not required, such as elevators. These Application Notes contain an extensive description of the configurations for both FreiTel-IP and Avaya Communication Manager which were used for testing.
- Page 2 Ethernet network, the LED turns red until the controller registers with a SIP proxy, at which time the LED turns green. The configuration used for testing consisted of a TAS FreiTel-IP control unit and a single speakerphone together with a pair of Avaya S8720 Server running Avaya Communication Manager, Avaya G650 Media Gateway, Avaya SIP Enablement Services (SES) server, and various Avaya telephones.
-
Page 3: Equipment And Software Validated
The TAS FreiTel-IP handsfree telephone is attached to Avaya Communication Manager via SIP trunk by way of the Avaya SIP Enablement Services (SES). The following table contains additional information about each of the telephones contained in the above diagram: Diagram... -
Page 4: Dial Plan Analysis Table
If these are not met in the configuration, please contact an Avaya representative for further assistance. Verify that the number of SIP trunks supported by the system is sufficient for the combination of trunks to the TAS FreiTel-IP and optional SIP endpoints to be supported. display system-parameters customer-options Page... - Page 5 Enter “y” to specify that direct IP-IP audio connections should be used. Connections Table 3: Configuration Signaling Group for SIP Interface to SES MRR; Reviewed: Solution & Interoperability Test Lab Application Notes 5 of 23 SPOC 12/13/2007 ©2007 Avaya Inc. All Rights Reserved. FreiTel-SIP...
-
Page 6: Signaling Group
Use the add trunk-group <x> command, where <x> is a free trunk group number, to create a trunk group which is to be used to connect to the Avaya SES. Accept defaults for parameters, except for those which are highlighted. - Page 7 SIP trunk. Enter the following parameters: Parameter Usage Use a location of “1”, in this example. Location Use a domain of “ffm.com”, as configured for Avaya SES in Figure 13. Authoritative Domain Assign a name for identification purposes. Name Intra-region IP-IP Specify “y”...
- Page 8 IP Codec Set Codec Set: 1 Silence Frames Packet Audio Suppression Per Pkt Size(ms) Codec 1: G.711A Figure 8: IP-Codec-Set Form MRR; Reviewed: Solution & Interoperability Test Lab Application Notes 8 of 23 SPOC 12/13/2007 ©2007 Avaya Inc. All Rights Reserved. FreiTel-SIP...
-
Page 9: Station Options
Survivable COR: internal Media Complex Ext: Survivable Trunk Dest? y IP SoftPhone? n Customizable Labels? y Figure 9: Station Form MRR; Reviewed: Solution & Interoperability Test Lab Application Notes 9 of 23 SPOC 12/13/2007 ©2007 Avaya Inc. All Rights Reserved. FreiTel-SIP... - Page 10 Figure 10: Off-PBX-Telephone Form, Page 1 3.2. Configure Avaya SIP Enablement Services Log in to the Avaya SES Web-based Integrated Management tool by selecting the IP address of the Avaya SES server followed by “/admin” from the Web browser. After entering the login ID and password, select “Launch Administration Web Interface”.
- Page 11 The SES Integrated Management top level menu is then displayed. Figure 12: SES Integrated Management Top Level Menu MRR; Reviewed: Solution & Interoperability Test Lab Application Notes 11 of 23 SPOC 12/13/2007 ©2007 Avaya Inc. All Rights Reserved. FreiTel-SIP...
- Page 12 SES server which was assigned in Figure 4 as the IP address of the “License Host”. Select the “Update” button. Figure 13: Avaya SES Edit System Properties Screen MRR; Reviewed: Solution & Interoperability Test Lab Application Notes...
- Page 13 From the top-level management screen, click “Manage Hosts” -> “Add Host”. Enter the Host IP Address of the Avaya SES Server, a DB password, and a Profile Service Password that were allocated to the Avaya SES server when it was installed. Leave the other fields assigned to their respective default values.
- Page 14 Assign a meaningful name to the “Media Server Interface Name”. Select the IP address of the Avaya SES server from the “Host” drop-down box. Enter the address of the Avaya S8720 CLAN interface as the SIP Trunk IP Address. Select the “Add” button when these parameters have been entered.
- Page 15 Figure 9 and for the off-pbx-telephone station- mapping in Figure 10. Enter a Password and First/Last name of the user, check the “Add Media Server Extension” box, and click “Add”. Figure 16: Avaya SES “Add User” Screen MRR; Reviewed: Solution & Interoperability Test Lab Application Notes...
- Page 16 Enter the Media Server Extension for the User ID 69001 (the extension of the Avaya SIP telephone). Select the Media Server (refer to Figure 15) from the drop-down box and click “Add” to continue. Figure 17: Avaya SES Add Media Server Extension Screen MRR;...
- Page 17 From the main menu, click the “Update” control in the left frame to commit the changes made. Figure 18: Update from Top SES Screen MRR; Reviewed: Solution & Interoperability Test Lab Application Notes 17 of 23 SPOC 12/13/2007 ©2007 Avaya Inc. All Rights Reserved. FreiTel-SIP...
- Page 18 3.3. Configure FreiTel-IP The TAS FreiTel-IP is configured via a terminal attached to the unit’s serial maintenance interface. From this terminal, it is also possible to temporarily enable a telnet interface, so that further configuration steps can be performed via a telnet session. However, the telnet interface should be disabled at completion of the configuration session for security reasons.
- Page 19 -Show Konfig. -Status -Debug - Temperatur Init - Audio Test manuell -Update Url -Logout Figure 19: FreiTel-IP Introductory Screen MRR; Reviewed: Solution & Interoperability Test Lab Application Notes 19 of 23 SPOC 12/13/2007 ©2007 Avaya Inc. All Rights Reserved. FreiTel-SIP...
- Page 20 Echo Pegelschwelle-Ein in Mode 7: 0 0 0 Echo Pegelschwelle-Aus in Mode 7: 0 0 0 Option: 3 Alarm Option: 10 Figure 20: FreiTel-IP Configuration Screen MRR; Reviewed: Solution & Interoperability Test Lab Application Notes 20 of 23 SPOC 12/13/2007 ©2007 Avaya Inc. All Rights Reserved. FreiTel-SIP...
-
Page 21: Test Results
4. Interoperability Compliance Testing The objective of the compliance testing performed on the TAS FreiTel-IP product was to verify that it is compatible with Avaya Communication Manager. This includes verifying that the essential FreiTel-IP features function properly when used with Avaya Communication Manager and that Avaya Communication Manager features are not hindered by the interaction with FreiTel-IP. -
Page 22: Verification Steps
FreiTel-IP unit which involve its telephone interface were tested. A detailed description of the configuration required for both the Avaya and the TAS equipment is documented within these Application Notes. The FreiTel-IP passed all of the tests performed, which included both functional and robustness tests. - Page 23 2007 Avaya Inc. All Rights Reserved. © Avaya and the Avaya Logo are trademarks of Avaya Inc. All trademarks identified by ® and ™ are registered trademarks or trademarks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners. The information provided in these Application Notes is subject to change without notice.
