SmartOnline
Intelligent True On-Line UPS Systems
Input/Output* Voltage: 220/380, 230/400, 240/415V AC, 3ø, 4 wire (plus ground), wye
For all UPS system modules (power module and battery module) sold either separately or combined.
Select UPS system modules may include separate instruction or warning sheets which should be used
Important Safety Warnings
Control Panel
Rear Panels
Installation
Operation (Normal Conditions)
Operation (Special Conditions)
Communications
Service/Warranty
Specifications
Español
Owner's Manual
3-Phase 20kVA & 30kVA
™
in conjunction with this manual.
1111 W. 35th Street • Chicago, IL 60609 USA
(773) 869-1234 • www.tripplite.com
Copyright ©2005 Tripp Lite. All rights reserved. SmartOnline™ is a trademark of Tripp Lite.
* User-selectable.
2
3
4
6
7
9
11
12
13
14
Advertisement
Table of Contents
Related Manuals for Tripp Lite SmartOnline 220/380
Summary of Contents for Tripp Lite SmartOnline 220/380
- Page 1 Español 3-Phase 20kVA & 30kVA ™ * User-selectable. in conjunction with this manual. 1111 W. 35th Street • Chicago, IL 60609 USA (773) 869-1234 • www.tripplite.com Copyright ©2005 Tripp Lite. All rights reserved. SmartOnline™ is a trademark of Tripp Lite.
-
Page 2: Important Safety Warnings
Equipment Connection Warnings • Do not use Tripp Lite UPS Systems in life support applications in which a malfunction or failure of a Tripp Lite UPS System could cause failure or significantly alter the performance of a life support device. -
Page 3: Control Panel
Control Panel There are two separate UPS system modules: a power module and a battery module. Familiarize yourself with the location and function of the features on each module before installing and operating your UPS system. The power module is the only module which includes front panel features. -
Page 4: Rear Panels
4. External Battery Terminal Block: Use this to connect a Tripp Lite battery module to the power module. Remove the cover for access. The power module will not start without a connection to a charged battery module. - Page 5 16. Cables for Battery Tray Interconnection (internal): connect the battery trays to supply DC battery power to a connected UPS System. 17. Cables for UPS System Connection (external): connect the internal batteries (through the fuse holder) to a compatible Tripp Lite UPS System.
-
Page 6: Installation
Installation UPS LOCATION Move your UPS over short distances using its wheels. Stabilize the UPS by releasing the stabilizers on each side of the unit. NOTE: Do not stack the UPS System power module or external battery modules. UPS POWER MODULE INPUT AND OUTPUT HARDWIRE CONNECTION In addition to the instructions listed below, follow all warnings found in the Safety section prior to connection. -
Page 7: Operation (Normal Conditions)
Installation (continued) WIRING CONNECTION Connect your wiring from the positive, negative and ground terminals on the UPS Battery Module to the positive, negative and ground terminals on the UPS Power Module. Qualified personnel should follow all procedures prescribed by N.E.C and other local codes for hardwiring devices. Ensure that cables are fitted with cable sleeves and are secured by connector clamps. -
Page 8: Self-Testing
Operation (Normal Conditions) SELF-TESTING When you turn the UPS ON, it will perform a brief self-test. See charts below for display sequences. Display sequence when AC input power is present: SELF TESTING... RECTIFIER OK CHARGER OK BATTERY OK DC TO DC OK INVERTER TEST LCD DISPLAY SELECT BUTTON Momentarily press the “SELECT”... -
Page 9: Operation (Special Conditions)
Operation (Special Conditions) OPERATION ON BYPASS—VOLTAGE OUT OF RANGE While in Bypass Mode, the UPS monitors the input voltage, which on Bypass equals the output voltage. If the output voltage passes out of an acceptable range (between 15% higher and 20% lower than nominal), the UPS displays the condition on its LCD and stops supplying output power to its load. -
Page 10: Operation Under Shutdown
Operation (Special Conditions) OPERATION UNDER SHUTDOWN Your UPS will shut down and the LCD will display a message if it detects one of the following conditions. Note: For all conditions, the “Input,” “Output” and “Bypass” LEDs will be illuminated. Condition LCD Display Message Overload Shutdown ON BYPASS... -
Page 11: Dry Contact Interface
RS-232 INTERFACE This female DB9 port connects your UPS via an RS-232 cable to a workstation or server equipped with Tripp Lite software. The port uses RS-232 communications to report UPS status and power conditions. Using this port, Tripp Lite software can monitor and manage network power, automatically save open files and shut down equipment during a blackout. -
Page 12: Remote Emergency Power Off (Epo)
WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or fitness of these devices for any specific application. The policy of Tripp Lite is one of continuous improvement. -
Page 13: Specifications
Regulatory Compliance Identification Numbers For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique series number. The series number can be found on the product nameplate label, along with all required approval markings and information. When requesting compliance information for this product, always refer to the series number. The series number should not be confused with the marking name or model number of the product. - Page 14 1111 W. 35th Street, Chicago, IL 60609 USA 773.869.1234 (USA) • 773.869.1212 (International) www.tripplite.com 2009XXXXX 93-2260_ES...
