Tripp Lite 2-9USTAND Owner's Manual

Audio/video pure sine wave ups systems
Hide thumbs Also See for 2-9USTAND:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Pure Sine Wave UPS Systems
Important Safety Instructions
Installation
Basic Operation
Troubleshooting
Battery Replacement
Storage and Service
Warranty Registration
200907169 93-2615.indd 1
Owner's Manual
Audio/Video
• Intelligent, True On-Line Operation
• Pure Sine-Wave Output
• Zero Transfer Time
• 1000VA - 2200VA Capacities
• Extended-Run Options
Not suitable for mobile applications.
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright ©2009 Tripp Lite. All rights reserved.
2
3
6
10
11
11
12
8/11/2009 10:14:56 AM

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite 2-9USTAND

Summary of Contents for Tripp Lite 2-9USTAND

  • Page 1 Not suitable for mobile applications. Important Safety Instructions Installation Basic Operation Troubleshooting Battery Replacement Storage and Service Warranty Registration 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support Copyright ©2009 Tripp Lite. All rights reserved. 200907169 93-2615.indd 1 8/11/2009 10:14:56 AM...
