Summary of Contents for Ocean Digital WR-03
- Page 1 Internet Radio Adaptor with DAB and Bluetooth WR-03 User Manual (Additional powered speaker/active speaker is required to use this product) Please read this user manual carefully before using the receiver.
-
Page 2: Table Of Contents
Contents Location of Controls ........1 Remote Control ..........2 Remote control character list ......3 Getting started ..........5 Connecting to your WiFi network .....6 Internet Radio ..........7 Spotify Connect ..........9 Media Center ..........10 FM mode .............12 DAB Mode ...........13 Information Center ........14 DLNA ............15 Bluetooth ............15 Configuration ..........16... -
Page 3: Location Of Controls
Location of Controls 1. 2.8'' TFT color screen 2. Infrared remote sensor 3. 3.5mm antenna input socket Two types of antenna are supplied with the radio. One is wire type and the other is the rod antenna. Apply one of them to get the best result on the reception of DAB and FM radio 4. -
Page 4: Remote Control
Remote control : Mute : Standby button 3. 0-9: Favorite station key / input letters and numbers for WiFi Encryption code : Preset the current playing station to Favorite : Recall the favorite list 6. ▲: Cursor up 7. t : Cursor left / back to previous menu 8. -
Page 5: Remote Control Character List
Remote control character list Key“0”―― 0,‘DEL’ Key“1”―― ‘1’->‘@’->‘ ’（ space） ->‘！’-> “ (double quotes) ->‘#’->‘$’->‘%’->‘&’-> ’（ single quotes）->‘（ ’ ->‘） ’->‘*’->‘+’->‘， ’->‘-’->‘.’->‘/’->‘:’->‘;’->‘<’->‘=’- >‘>’->‘?’- >‘[’->‘\’->‘]’->‘^’->‘_’->‘`’->‘{’->‘|’->‘}’->‘~’ Key “2”―― 2,A,B,C,a,b,c Key“3”―― 3,D,E,F,d,e,f Key“4”―― 4,G,H,I,g,h,i Key“5”―― 5,J,K,L,j,k,l Key“6”―― 6,M,N,O,m,n,o Key“7”―― 7,P,Q,R,S,p,q,r,s Key“8”―― 8,T,U,V,t,u,v Key“9”―― 9,W,X,Y,Z,w,x,y,z To enter the password, press "... - Page 6 Before you start Please ensure the following is ready: • You have a broadband internet connection. • A wireless (Wi-Fi) broadband router is connected to the internet successfully. The radio supports Wireless B, G and N connection (Wireless N router can also be used with the setting on B or G).
-
Page 7: Getting Started
Getting started Connect the mains adaptor to the radio unit, one end to the DC IN on the radio and the other end to the mains wall outlet. Caution: Use only the mains adaptor supplied with the radio. Connecting a power supply with a different rating will cause permanent damage to the radio and may be hazardous. -
Page 8: Connecting To Your Wifi Network
Connecting to your WiFi network The following screen will appear. You can choose <Yes> to proceed to search for the available WiFi network. If your router has the WPS function, you can select <Yes(WPS)> to proceed. 01:01 Would you like to configure Network now? Yes(WPS) It will then start scanning the network. -
Page 9: Internet Radio
Internet Radio Choose <Internet Radio> from the menu, you can see different functions as below: To start listening the radio stations worldwide, select <Radio Station/Music>. My Favorite This is to show the list of your Favorite stations which have been assigned to the presets. - Page 10 Internet Radio Shift down – To shift the selected station by one level down on the ranking Rename – To rename the selected station Play – press and play the selected station Choose the radio station that you want to make with the above changes.
-
Page 11: Spotify Connect
A better way to listen at home. Listen on the WR-03 using the Spotify app as a remote. Enjoy the music together. Use your phone, tablet or computer as a remote control for Spotify.Go to spotify.com/connect to learn how. The Spotify Software is subject to third party licenses found here:www.spotify.com/connect/third-party-licenses... -
Page 12: Media Center
Media Center UPnP (Universal Plug and Play) The device supports UPnP and is DLNA-compatible. This provides the opportunity to stream music from your other network devices. However, this requires you to have a compatible device in your network that can function as a server. This can be e.g., a network hard drive or a conventional PC with e.g., Windows 8 via which access to the shared folder or media sharing is permitted. - Page 13 Media Center My Playlist You can make your own playlist from the UPnP music files. Choose and highlight the song you want to add to playlist, press and hold the [Dial/Select] knob, unit the sign appears. The song will be added to My playlist. Clear My Playlist Remove all songs in My playlist to allow a new playlist to be prepared.
-
Page 14: Fm Mode
FM Mode You can listen to the ordinary FM radios without wifi connection. Take out the wire antenna supplied in the package, plug it into the antenna socket on the rear side of the adaptor, extend it perpendicular to the radio unit or in other direction / length of the antenna may be required to optimize the reception level. -
Page 15: Dab Mode
DAB Mode You can listen to ordinary DAB channels without wifi connection. Take out the wire antenna supplied in the package, plug it into the antenna socket on the rear side of the adaptor, extend it perpendicular to the radio unit or in other direction / length of the antenna may be required to optimize the reception level. -
Page 16: Information Center
Information Center Weather The radio provides weather information and can display in Standby mode. To enable this feature, follow the steps below: Go to main menu, choose Information Center> Weather Information, choose the region you want it to display the weather information. -
Page 17: Dlna
Bluetooth devices. 1. Turn on Bluetooth on the Bluetooth device and look up the device named “WR-03” from the list. Select it to start pairing. 2. If the connection is successful, it will show “Connected” on your Bluetooth device list. -
Page 18: Configuration
Configuration Time Display You can choose the time display at Analog or Digital. Manage my mediaU You can tailor made your own favorite station list using your computer. 1) Go to http://www.mediayou.net/ and sign up to become a member. 2) Then you have to find out the Mac Address to register on the Media U website. - Page 19 Configuration Note: If you are going to add URL which is not on Media U database, ensure the URL is an audio streaming URL or contact Media U to add it for you. - 17 -...
- Page 20 Configuration It allows maximum 5 users to register with the same radio and you can switch to listen the favorite list under one user at a time. To find your added station / custom favorite list on the radio, go to Configuration >...
- Page 21 Configuration Date Format setting Date format: YYYY/MM/DD, DD/MM/YYYY and MM/DD/YYYY If manual setup is selected, you will see an added item Daylight Saving Time (DST) setting appeared on the list. Alarm Dual alarm clock There are 2 alarm clocks available and settings as follow: Scheduling alarm: You can schedule the alarm repeated for every day, particular day in the week or just once.
- Page 22 Configuration Language There are 17 Languages available, such as English, German, French, Norwegian, Italiano, Svenska, Dansk and others. Dimmer You can adjust the backlight of the LCD with below settings: Power Saving You can set the backlight to dim down when there is no operation for a certain time of period.
- Page 23 Configuration Weather You can set to display the weather information in standby mode by choosing different regions and the temperature unit. DAB/FM Setup FM Mode Option to choose hearing in Stereo or mono. Note: As the radio is a mono, this option does not apply. FM Threshold Option to adjust the scanning threshold to pick up stronger or weaker FM stations.
- Page 24 Configuration ABC dig Now playing: Don’t Explain, Artist: Billie Hoilday (Dzihan & Kamien), Album:Verve List radio mode to play the corresponding channel. Local Radio Setup The radio will detect your local area stations automatically and simply press <Local> to access the radio stations in your local area.
- Page 25 Configuration Android: iOS: Equalizer Select your prefer equalizer to suit your listening preference. Resume When Power On The radio will resume playing the last listened station when you power it on next time if ON is selected in this option. The ON is set by default.
-
Page 26: Trouble Shooting
Trouble Shooting 1. If you have trouble connecting the radio to your wireless network, these steps may help to resolve the problem: - Confirm that a Wi-Fi or Ethernet Wired connected PC can access the internet (i.e. can browse the web) using the same network. - Page 27 Trouble Shooting - The internet connection between the server (often located in a different country) and yours is slow. Some internet service providers may fail to stream in certain geographical areas. Try using a PC to play back the stream via the broadcaster ’s web site.
- Page 28 Trouble Shooting high error rate or disconnections. If you are experiencing these problems, you will need to contact your broadband supplier. 6. What is Buffering? When playing a stream, the Internet Radio/Media player, downloads a small amount of the stream before it starts playing. This is used to fill in any gaps in the stream that may occur if the internet or the wireless network is busy.
-
Page 29: Technical Specification
This system is financed by the industry and ensures environmentally responsible disposal and the recycling of valuable raw materials. Ocean Digital Technology Ltd. Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road, Kowloon Bay, Hong Kong Email: support@oceandigital.com.hk...
