Summary of Contents for Ocean Digital WR-800F
- Page 1 Stereo Internet Radio WR-800F User Manual Please read this user manual carefully before using the receiver Please read this user manual carefully before using the receiver.
-
Page 3: Table Of Contents
Contents Location of Controls ..............Remote control ................6 Entering the passcode of the wireless network ......7 1. To start up ................9 . Network Setup ..............Overview of features and functions ........4. Internet Radio ..............12 . Media Centre ..............6. -
Page 4: Location Of Controls
Location of Controls 17 18 - 4 -... - Page 5 Location of Controls Press to toggle between Standby & Operational Press to display the sleep timer intervals: 15/30/45/60/90/120/180 minutes Press to recall Favorite list; long press to add a playing station to favorite list 4. Preset button 1-3 Assign the top 3 favorites to the button 1-3 Press and hold to preset Press it briefly to recall Access Home screen/Press this button to return to the now playing screen (or...
-
Page 6: Remote Control
Remote Control : Press to toggle between Standby and Operation : Mute 3. 0-9: Input index number on the list / input characters for WiFi passcode : Preset the now playing station to Favorite 5. ▲ : Cursor up 6. ◄ : Cursor left / back to previous menu : Alarm button : Sleep Timer 9. -
Page 7: Entering The Passcode Of The Wireless Network
Entering the passcode of the wireless network Using remote control On the alpha-numeric keypad, press the button repeatedly to cycle through the characters assigned to each button. Refer to the following list. To input a character, highlight it and press the [ OK ] button to confirm and input the next character. - Page 8 Before you start Please ensure the following is ready: You have a broadband internet connection. A wireless broadband router is connected to the internet successfully. The radio supports Wireless B, G and N connection (Wireless N router can also be used with the setting on B or G).
-
Page 9: To Start Up
1. To start up • Remove internet radio from the package box. • Plug in the power adapter and turn the radio on by the power switch located at the rear panel of the radio. ◦ Caution: Use only the adaptor supplied with the radio. Connecting a power supply with a different rating will cause permanent damage to the radio and may be hazardous. -
Page 10: Network Setup
2. Network Setup Internet connection is setup via Wireless network (WiFi). A broadband internet connection is required. • If this is first time use, the Configure Network wizard will be displayed. Choose Yes to start configuring network. Press the [ ◄ ] button to highlight Yes and press [NAVIGATE/ENTER] to confirm. -
Page 11: Overview Of Features And Functions
3. Overview of features and functions Press [ ] to enter the Home screen. Scroll by rotating the [NAVIGATE/ENTER] knob or the [ ◄ / ► ] button on remote: My Favorite - To show the list of favorite stations which have been assigned to the presets. -
Page 12: Internet Radio
4. Internet Radio On the Home screen, choose Internet Radio and you will find the options below: 12:01am Internet Radio < Skytune > Search(Skytune) > History > Skytune Select Skytune to start enjoying thousands of radio stations over the world. You can filter your search by Region, Music genre and talks. - Page 13 4. Internet Radio Every time the ► button is pressed, it will display the radio channel information and a big clock: My Favorite This is to show the list of your Favorite stations which have been assigned to the presets. Preset a station When a radio station is playing, press the button on the remote control or press...
-
Page 14: Media Centre
5. Media Centre The device supports UPnP and is DLNA-compatible. This provides the opportunity to stream music from your network. However, this requires you to have a compatible device in your network that can function as a server. This can be e.g., a network hard drive or a conventional PC with e.g., Windows 8 via which access to the shared folder or media sharing is permitted. -
Page 15: Fm Radio
6. FM Radio To receive the ordinary FM stations (no internet connection is required), place the radio close to the window and extend the antenna as far as it can go to get the best reception. You may need to adjust the direction of the antenna to improve reception. On the Home screen, scroll to FM Radio or use the [MODE] button on remote to switch to FM Radio. -
Page 16: Bluetooth Playback
The device scans for Bluetooth devices in the reception range. • When the radio is found, your bluetooth device shows its name WR-800F-XXXX (the XXXX is an identification code for your radio unit). • Select the radio at your bluetooth device. -
Page 17: Alarm Setting
8. Alarm Setting • Choose Alarm from the Home screen or press the [ ] button on the remote control. • Select either Alarm 1 or Alarm 2, choose Turn on to activate the Alarm. • Follow the alarm wizard instructions to set the alarm. •... -
Page 18: Sleep Timer Setting
9. Sleep Timer Setting The radio will turn to sleep mode after a specified time period has elapsed. The timer options are 15/30/45/60/90/120/180 minutes. Press [ ] button on the remote control or press button on the unit to set the timer. -
Page 19: Configuration
10. Configuration Here you will find the complete settings / options available to configure your own radio. On the Home screen, navigate to Configuration setting. Press OK and you will see a list of options available. Network • Network Options Always on: The WLAN function remains switched on (faster access when switching from other modes of radio). - Page 20 10. Configuration 4. Enter the password of your network. 5. Tap "Multicast" followed by "Confirm" to complete. 6. The radio will start associating with the network and followed with the message "Association complete" if network is successfully connected. Remove AP - If you have already added a router and want to remove it, choose this option.
- Page 21 10. Configuration • IP The IP is set Dynamic by default. Select to change Fixed IP according to your network condition. • DNS The DNS is set Dynamic by default. Select to change <Fixed> DNS according to your network condition. Date and Time The radio will set your local time automatically after the internet connection is completed.
- Page 22 10. Configuration Language You can choose other languages as preferred. Scroll with the ▲▼ buttons on remote or [NAVIGATE/ENTER] knob to the item with and press [NAVIGATE/ENTER] or OK on remote. Scroll to highlight and press [NAVIGATE/ENTER] or OK on remote to select your language of choice. English, French, Spanish, Italian, German, Dutch, Polish, Russian and Simplified Chinese are available.
- Page 23 10. Configuration Dim - This is to adjust the level of brightness in Dim mode. • Dimmer in Standby The display brightness in standby mode can be adjusted manually by turning the rotary knob [NAVIGATE/ENTER] or press the ▲▼ buttons on remote. If no action taken in 20 seconds, it will stay with the dim value as set in Configuration.
-
Page 24: Remote Control Via Pc / Smart Phone
11. Remote control via PC / Smart phone - Tuning internet radio & manage favourites Experience an easy way to control tuning internet radio channels and manage your favourite list via PC or Smart phone's web browser. The supported browsers are Internet Explorer and Chrome. - Connect your PC or Smart phone to the same Wi-Fi network as your radio. - Page 25 11. Remote control via PC / Smart phone - Tuning internet radio & manage favourites - It will prompt you whether to "Add Favourite" or "Listen to Station". Enter the IP address of your radio (e.g. 192.168.1.11): The IP address can be located on the radio unit as follow: * On the remote control, press the [INFO] button, choose Network and scroll to IP to view the IP address * On the radio, return to the Home screen.
- Page 26 11. Remote control via PC / Smart phone - Tuning internet radio & manage favourites You can also add the radio channel if you know the published audio stream URL with the streaming format as follow: 1. Audio formats: MP3, AAC, AAC+ 2.
-
Page 27: Trouble Shooting
12. Trouble Shooting Cause Problem Solutions • Confirm that a Wi-Fi or Ethernet Wired connected PC can access the internet (i.e. can browse the web) using the same network. • Check that a DHCP server is available, or that you have configured Network down a static IP address on the radio. - Page 28 12. Trouble Shooting Cause Problem Solutions • The station is not broadcasting at this time of the day (remember it may be located in a different time zone). If your radio • The station has too many people trying can connect to to attach to the radio station server and the network the server capacity is not large enough.
-
Page 29: Helpful Tips
Helpful Tips 1. If the Internet Radio keeps re-buffering radio station: The Internet Radio is streaming the data from the radio station via your broadband connection, if there is a high error rate on your broadband connection, or the connection is intermittent, then it will cause the Internet Radio to pause until the connection is re-established and it has received enough data to start playing again. -
Page 30: Technical Specification
Technical Specification Model WR-800F Power input Power voltage 100-240V~50/60Hz IEEE802.11b/g/n Wireless Network Wireless network frequency 2412 - 2484 MHZ Typical transmission power 14 dBm (72.2 Mbps); Wireless transmission power 20 dBm (11b mode) Security Protocol WEP/WPA/WPA2 V4.2 BR/EDR compliant Bluetooth version Bluetooth frequency 2.4 GHz... -
Page 31: In The Box
This system is financed by the industry and ensures environmentally responsible disposal and the recycling of valuable raw materials. Ocean Digital Technology Ltd. Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road, Kowloon Bay, Hong Kong Email: support@oceandigital.com.hk...
