- Page 1 Internet Radio WR-336N User Manual Please read this user manual carefully before using the receiver Please read this user manual carefully before using the receiver.
-
Page 3: Table Of Contents
Contents Location of Controls ..............1 Remote control ................2 How to input password for your wireless network ......3 1. Getting started ..............5 2. Charging battery ..............5 . Network Setup ..............Overview of features and functions ......... Internet Radio ............... -
Page 4: Location Of Controls
Location of Controls DCIN5V LINEOUT 7 2 5 8 Press and hold to power on/off Press and release to Standby / activate the radio (Standby is enabled only when power is connected. It will be disabled when internal battery is used) Access main menu/press this button to return to the playing screen Press and hold to preset a particular station Press to recall the favourite list... -
Page 5: Remote Control
Remote Control : Press to toggle between Standby and Operation (applicable only when Standby is enabled with power connected to the radio) : Mute 3. 0-9: Input index number on the list / input characters for WiFi password : Preset the current playing station to Favorite 5. -
Page 6: How To Input Password For Your Wireless Network
How to input password for your wireless network Using remote control On the alpha-numeric keypad, press the button repeatedly to cycle through the characters assigned to each button. Refer to the following list. To input a character, highlight it and press the ► button to confirm and input the next character. - Page 7 Before you start Please ensure the following is ready: You have a broadband internet connection. A wireless broadband router is connected to the internet successfully. The radio supports Wireless B, G and N connection (Wireless N router can also be used with the setting on B or G).
-
Page 8: Getting Started
Getting started/Charging battery 1. Getting started The radio is powered by the built-in lithium battery. A USB cable is supplied in the product package. Press and hold the [ ] button to power on. To power off the radio, press and hold the same button. The Standby mode is enabled only when the power is connected and so to make use of the Alarm clock function. -
Page 9: Network Setup
3. Network Setup Internet connection can be setup via Wireless network (WiFi). Your radio requires a broadband Internet connection. • If this is first time use, the Configure Network wizard will be displayed. Choose Yes to start configuring network. Press the [ ◄ ] button to highlight Yes and press [Dial/Select] to confirm. -
Page 10: Overview Of Features And Functions
4. Overview of features and functions Press [ ] to enter the main menu. Scroll by rotating the [Dial/Select] knob or the [ ◄ / ► ] button on remote: My Favorite - To show the list of favorite stations which have been assigned to the presets. -
Page 11: Internet Radio
5. Internet Radio On the main menu, choose Internet Radio and you will find the options below: Skytune Search History Skytune Select Skytune to start enjoying thousands of radio stations over the world. You can filter your search by Region, Music genre and talks. The Local Radio let you access quickly the stations available in your local area through internet connection. - Page 12 5. Internet Radio Every time you press the ► button, it will toggle between the big clock and the radio channel information: My Favorite This is to show the list of your Favorite stations which have been assigned to the presets.
-
Page 13: Media Centre
6. Media Centre The device supports UPnP and is DLNA-compatible. This provides the opportunity to stream music from your network. However, this requires you to have a compatible device in your network that can function as a server. This can be e.g., a network hard drive or a conventional PC with e.g., Windows 8 via which access to the shared folder or media sharing is permitted. -
Page 14: Bluetooth Playback
The device scans for Bluetooth devices in the reception range. • When the radio is found, your bluetooth device shows its name WR-336N-XXXX (the XXXX is an identification code for your radio unit). • Select the radio at your bluetooth device. -
Page 15: Alarm Setting
8. Alarm Setting Important! In order to use the Alarm clock function, please have the radio connected with a power supply so to have the Standby mode enabled. When the radio is turned on, press and release the [ ] button to put the radio into standby. Standby is disabled when the radio is using internal battery. -
Page 16: Sleep Timer Setting
9. Sleep Timer Setting You can set the timer to let the radio turns off after the selected time elapsed in the range of 15 minutes to 180 minutes. Press [ ] button on the remote control to set the timer. You will see the icon appeared on the display if the timer is set. -
Page 17: Configuration
10. Configuration Here you will find the complete settings / options available to configure your own radio. On the main menu, navigate to Configuration setting. Press OK and you will see a list of options available. Network • Network Options Always on: The WLAN function remains switched on (faster access when switching from other modes of radio). - Page 18 10. Configuration 4. Enter the password of your network. 5. Tap "Multicast" followed by "Confirm" to complete. 6. The radio will start associating with the network and followed with the message "Association complete" if network is successfully connected. Remove AP - If you have already added a router and want to remove it, choose this option.
- Page 19 10. Configuration • IP The IP is set Dynamic by default. Select to change Fixed IP according to your network condition. • DNS The DNS is set Dynamic by default. Select to change <Fixed> DNS according to your network condition. Date and Time The radio will set your local time automatically after the internet connection is completed.
- Page 20 10. Configuration Language The default language is English, you can choose other languages as preferred. Scroll with the ▲▼ buttons on remote or [Dial/Select] knob to the item with and press OK. Scroll to highlight and press OK to select your language of choice. English, French, Spanish, Italian, German, Dutch, Polish, Russian and Simplified Chinese are available.
- Page 21 10. Configuration EQ(Equaliser) Various music genres can be set. Buffer Time Sometimes you may experience uneven playback of the internet radio. This can happen if the internet connection is slow or network congestion occurs. To help improving the situation, you can choose longer buffer time to get a few seconds of radio stream before beginning to play.
-
Page 22: Remote Control Via Pc / Smart Phone
11. Remote control via PC / Smart phone - Tuning internet radio & manage favourites Experience an easy way to control tuning internet radio channels and manage your favourite list via PC or Smart phone's web browser. The supported browsers are Internet Explorer and Chrome. - Connect your PC or Smart phone to the same Wi-Fi network as your radio. - Page 23 11. Remote control via PC / Smart phone - Tuning internet radio & manage favourites - It will prompt you whether to "Add Favourite" or "Listen to Station". Enter the IP address of your radio (e.g. 192.168.1.11): The IP address can be located on the radio unit as follow: * On the remote control, press the [Info] button, choose Network and scroll to IP to view the IP address * On the radio, return to the main menu.
- Page 24 11. Remote control via PC / Smart phone - Tuning internet radio & manage favourites You can also add the radio channel if you know the published audio stream URL with the streaming format as follow: 1. Audio formats: MP3, AAC, AAC+ 2.
-
Page 25: Trouble Shooting
12. Trouble Shooting Cause Problem Solutions • Confirm that a Wi-Fi or Ethernet Wired connected PC can access the internet (i.e. can browse the web) using the same network. • Check that a DHCP server is available, or that you have configured Network down a static IP address on the radio. - Page 26 12. Trouble Shooting Cause Problem Solutions • The station is not broadcasting at this time of the day (remember it may be located in a different time zone). If your radio • The station has too many people trying can connect to to attach to the radio station server and the network the server capacity is not large enough.
-
Page 27: Helpful Tips
Helpful Tips 1. If the Internet Radio keeps re-buffering radio station: The Internet Radio is streaming the data from the radio station via your broadband connection, if there is a high error rate on your broadband connection, or the connection is intermittent, then it will cause the Internet Radio to pause until the connection is re-established and it has received enough data to start playing again. -
Page 28: Technical Specification
Technical Specification Model WR-336N Power input Power voltage 100-240V~50/60Hz IEEE802.11b/g/n Wireless Network Wireless network frequency 2412 - 2484 MHZ Typical transmission power 14 dBm (72.2 Mbps); Wireless transmission power 20 dBm (11b mode) Security Protocol WEP/WPA/WPA2 V4.2 BR/EDR compliant Bluetooth version Bluetooth frequency 2.4 GHz... -
Page 29: In The Box
This system is financed by the industry and ensures environmentally responsible disposal and the recycling of valuable raw materials. Ocean Digital Technology Ltd. Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road, Kowloon Bay, Hong Kong Email: support@oceandigital.com.hk...
