- Page 1 BNI IOL-106-000-Z012 BNI IOL-106-S01-Z012 BNI IOL-106-S01-Z012-C01 User´s Guide...
-
Page 2: Table Of Contents
Voltage Monitoring Index 44hex Identification Index 60hex 4.4. Errors 4.5. Events Technical Data 5.1. Dimensions 5.2. Mechanical Data 5.3. Electrical Data 5.4. Operating conditions 5.5. LED indicators Status LEDs LED I-Ports Standard Appendix 6.1. Product ordering code 6.2. Order information Included material www.balluff.com... -
Page 3: Notes For The User
Notes for the user 1.1. About this guide This guide describes the Balluff Network Interface BNI IOL-106-xxx-Z012 for the application as peripheral input module to establish connection of binary sensors. Hereby it is about an IO-Link device which communicates by means of IO-Link protocol with the superordinate IO- Link master assembly. -
Page 4: Safety
Safety 2.1. Intended use This guide describes the Balluff Network Interface BNI IOL-106-xxx-Z012 for the application as peripheral input module to establish connection of binary sensors. Hereby it is about an IO-Link device which communicates by means of IO-Link protocol with the superordinate IO- Link master assembly. -
Page 5: Getting Started
Balluff Network Interface / IO-Link BNI IOL-106x-x0x-Z012 Getting Started 3.1. Connection overview BNI IOL- 106…Z012 Fig. 3-1: BNI IOL-106-xxx-Z012 1 Mounting hole 9 Pin/Port LED: Signalstatus 2 Label 10 Standard I port 6 3 Status LED: Communication 11 Standard I port 4... -
Page 6: Mechanical Connection
The FE connection from the housing to the machine must be low-impedance and kept as short as possible. Module versions Sensor Hub Version Digital Port BNI IOL-106-000-Z012 16 Inputs BNI IOL-106-S01-Z012 16 Inputs with single channel monitoring BNI IOL-106-S01-Z012-C01 16 Inputs with single channel monitoring and identification... -
Page 7: Sensor Interface
Balluff Network Interface / IO-Link BNI IOL-106x-x0x-Z012 Getting Started 3.4. Sensor Interface Standard I-port (M12, A-coded, female) Function +24V, 100mA Sinking (NPN) Input 2 Sinking (NPN) Input 1 Note, Tipp For the digital inputs follow the input guideline per EN 61131-2, Type 2. -
Page 8: Getting Started
Getting Started 4.1. IO-Link Data BNI IOL-106-000-Z012 Data transmission rate COM2 (38,4 kBaud) Minimal cycle time 3 ms Process data lenght 2 Byte input IO-Link Revision Frame typ Process data cycle time* 3 ms 3 ms * by min. cycle time... -
Page 9: Prozess Data / Input Data
Balluff Network Interface / IO-Link BNI IOL-106x-x0x-Z012 Getting Started 4.2. Prozess data / Input data BNI IOL-106-000-Z012 Byte BNI IOL-106-S01-Z012 Byte Byte www.balluff.com... - Page 10 Getting Started BNI IOL-106-S01-Z012-C01 Byte Byte Byte Identificationbyte 0 Identificationbyte 1 www.balluff.com...
-
Page 11: Parameter Data / Request Data
Balluff Network Interface / IO-Link BNI IOL-106x-x0x-Z012 Getting Started 4.3. Parameter data SPDU Object name Length Range Default Value / Request data Index Index Sub- index Vendor ID 2 Byte 0378 050711 050712 Device ID 3 Byte 050713 Vendor name... -
Page 12: Inversion Of The Inputs Index 40Hex
Getting Started Inversion of the Byte inputs Index Index Inversion port (x): 0 - Normal 1 - Inverted www.balluff.com... -
Page 13: Voltage Monitoring Index 44Hex
Balluff Network Interface / IO-Link BNI IOL-106x-x0x-Z012 Getting Started Voltage Byte Monitoring Index 44 Index Short Circuit port x = 1 Short Circuit on port x between Pin 1 and Pin 3 Port x = 0….7 Identification Byte Index 60... -
Page 14: Errors
Parameter Value out of Range 0x8033 Paremeter length overrun 0x8034 Parameter length underrun 4.5. Events IO-Link Revision 1.0 Event Code Description 0x5112 Low sensor voltage (US) 0x5410 Short circuit IO-Link Revision 1.1 Event Code Description 0x5111 Low sensor voltage (US) 0x7710 Short circuit www.balluff.com... -
Page 15: Technical Data
Balluff Network Interface / IO-Link BNI IOL-106x-x0x-Z012 Technical Data 5.1. Dimensions 5.2. Mechanical Data Housing material Die-cast zinc housing IO-Link-Port M12, A-coded, male, E-Ports M12, female, 5-poles Enclosure rating per IEC 60529 IP67 (only when plugged in and threaded in) Weight ca. -
Page 16: Led Indicators
Supply Sensors & Module ok / Undervoltage LED 6 Green / Green flashing Communcation error / communication ok LED I-Ports Indicator Function LED Pin 2 / Pin 4 Standard Input signal = 0 Yellow static Input signal = 1 Port: SC, short circuit www.balluff.com... -
Page 17: Appendix
Balluff Network Interface / IO-Link BNI IOL-106x-x0x-Z012 Appendix 6.1. Product BNI IOL-x0x-xxx-Z012-C01 ordering code Balluff Network Interface IO-Link Interface Functions 106 = 16 NPN digital Inputs Versions 000 = Standard version S01 = with single channel monitoring Mechanical design Z012 = Die-cast zinc housing, matte nickel plated... - Page 18 Notes www.balluff.com...
- Page 19 Balluff GmbH Schurwaldstrasse 9 73765 Neuhausen a.d.F. Germany Tel. +49 7158 173-0 Fax +49 7158 5010 www.balluff.com balluff@balluff.de...
