GrowSpan 500 Series Manual

W/blackout system, ventilation & evaporative cooling. 30' wide accessories: fans, shutters & light traps
Hide thumbs Also See for 500 Series:

Advertisement

Quick Links

Download this manual
Series 500 Greenhouse Kit w/Blackout System,
Ventilation & Evaporative Cooling
WHITE - Accessories
©2019 GrowSpan
All Rights Reserved. Reproduction
GB30PVWHITE
is prohibited without permission.
30' Wide Series 500 Accessories:
Fans, Shutters & Light Traps
Revision date: 04.18.19
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 500 Series and is the answer not in the manual?

Questions and answers

Related Manuals for GrowSpan 500 Series

Summary of Contents for GrowSpan 500 Series

  • Page 1 Series 500 Greenhouse Kit w/Blackout System, Ventilation & Evaporative Cooling WHITE - Accessories ©2019 GrowSpan All Rights Reserved. Reproduction GB30PVWHITE is prohibited without permission. 30' Wide Series 500 Accessories: Fans, Shutters & Light Traps Revision date: 04.18.19...

  • Page 2: Color Coding

    Color Coding READ THIS BEFORE YOU BEGIN Purchased greenhouse and all accessories & systems require a specific installation sequence. All components have been separated into different categories based on common grouping and/or the chronology of installation. Each category has been color coded. All parts within any given color category will be labeled accordingly, and each color category will have its own respective instruction manual.
  • Page 3 Color Coding WHITE Accessories Installation Chronology MUST READ: All components that are color coded WHITE represent the accessories of the greenhouse, including exhaust fans, ceiling fans and breathable wall light traps. ***Color coded components that MUST be installed before installing WHITE: ORANGE GREEN PINK...
  • Page 4 Important Information READ THIS DOCUMENT BEFORE YOU BEGIN TO INSTALL THE END CLADDING. Thank you for purchasing a Series 500 greenhouse kit with a black-out system, ventilation & evaporative cooling. When properly assembled and maintained, this product will provide years of reliable service. These instructions include helpful hints and important information needed to safely assemble and properly UNPACK AND IDENTIFY PARTS...
  • Page 5 Fans, Shutters & Adaptor Boxes INSTALL SLANT FANS, SHUTTER ASSEMBLIES & ADAPTER BOXES Adaptor boxes need to be installed before the end wall polycarbonate cladding is to be attached, but because the light trap components cannot be exposed to direct sunlight for extended periods of time, DO NOT install the light traps at this time.
  • Page 6 Fans, Shutters & Adaptor Boxes 3. With assistance, center adapter box over fan and shutter opening and on top of Tek screws. 4. Hold box in place and use a level to ensure box is positioned correctly. 5. From outside end wall, run a drill bit through all mounting holes (drilled in previous step) to mark these locations on the adapter box flange.
  • Page 7 Fans, Shutters & Adaptor Boxes 9. With assistance, lift box back into position to check mounting hole alignment with bolts. Ream mounting holes as needed to allow box to slide onto each mounting bolt. Once you are able to easily place adapter box in position, carefully set it on a flat surface with its mounting flange facing up.
  • Page 8 Light Traps ASSEMBLE LIGHT TRAP VANE KIT COMPONENTS WARNING: To prevent damage to the light trap components DO NOT expose to direct sunlight for extended periods of time. If possible, do not complete this step until film cover (GREEN) has been installed to protect from the sun. Diagrams below shows basic light trap to adapter box connection.
  • Page 9 Light Traps 16 " BREATHABLE WALL LIGHT TRAP with FRAME: 4'x4' 16 " 116168 " 113392 116152 116155 113423 116168 " FRONT VIEW 116139 116153 16 " 116152 116154 113423 FRONT VIEW FRONT VIEW 116139 16 " " BREATHABLE WALL LIGHT TRAP with FRAME: 6'x6' "...
  • Page 10 Light Traps ASSEMBLE LIGHT TRAP VANE KIT COMPONENTS 4. Slide a tube spacer onto each rod and add another Size of vane kits is dependent on greenhouse length. vane. Purchased vane kit may not match vane kits shown 5. Repeat Step 4 until all vanes are used. in diagrams.
  • Page 11 Light Traps ASSEMBLE LIGHT TRAP VANE KIT FRAME Gather parts: • Light trap frame side panels (2) • 116139 rivets • Light trap aluminum angle (sides) (2) • Light trap frame top/bottom • Light trap aluminum angle (top/bottom) (2) panels (2) Complete these steps: 1.
  • Page 12 Light Traps INSTALL LIGHT TRAP 1. Tighten all nuts and remove clamps if used. 2. Attach light trap to adapter box. ATTENTION: Each 1/4" nut and bolt combination uses two (2) flat washers–one installed against the bolt head and one installed against the locknut. For easier bolt installation, lift the light trap into position, align all bolt holes, and clamp the components together.
  • Page 13 Ceiling Circulation Fans INSTALL CEILING FANS 1. Consult layout diagram below and determine fan locations. Avoid obstructing webbing and/or blackout components. If necessary, consult PURPLE and BLACK instructions manuals to familiarize with those component locations, and/ or install those components first before installing ceiling circulating fans. 2.

  • Page 14: Additional Notes

    Additional Notes Space below is reserved for customer notes. Revision date: 04.18.19...
