Color
Green
Green
Green
Table 1-6: Right Ethernet Port LED
Color
Green
Green
Green

Drive carrier LEDs

A diagram of the LED states of the ProStream X drive carriers.
Table 1-7: Drive Status LED States (Amber)
State
Off
Solid On
Table 1-8: Drive Activity LED States (Green)
Condition
Power on with no drive activity
Power on with drive activity
Power on and drive spun
down
Power on and drive spinning
up
LED State
Off
On
Blinking
LED State
On
On
On
Description
No access and no fault
Hard drive fault has occurred
Drive Type
SATA
SATA
SATA
SATA
13
Drive carrier LEDs
NIC State
LAN link not established
LAN link is established
LAN activity is occurring
NIC State
10 Mb/sec data rate
100 Mb/sec data rate
1000 Mb/sec data rate
Description
LED stays off
LED blinks off when
processing a command
LED stays off
LED stays off
