Introduction - How to use Grandstream HT-386 with PBXware This "How to" is written to as general guide on how to use your Grandstream HT-386 with PBXware using 1.0.2.16 Grandstream HT-386 firmware. It covers the most common tasks required in order to have your Grandstream HT-386 working efficiently.
Registering Grandstream HT-386 Requirements 1. Grandstream HT-386 firmware. - Make sure that device is loaded with 1.0.2.16 firmware. 2. DHCP server. - Fully configured and operational DHCP server. Manual Configuration UAD Settings STEP ONE: PBXware IP address. 1. Find out the IP address of PBXware server.
Page 3
STEP THREE: UAD status. 1. Make sure the UAD is enabled. To check the UAD status navigate to "Settings:UAD", and click on the "edit" icon corresponding to "Grandstream HT-386".
Page 4
2. Make sure "Status" is set to "active", "Auto provisioning" is set to "No" and "DHCP" is set to "Yes".
Page 5
STEP ONE: Add Extension. 1. Navigate to "Extensions". Click on "Add Extension". 2. The standard options window will be shown below. 3. Select Grandstream HT-386 from "UAD" select box. 4. Select Location: "Local" or "Remote". Note: -"Local" is for all extension registered on LAN.
Page 6
5. Click on the "Next" button. STEP TWO: Extension values. 1. Enter values into the required field text boxes. REQUIRED FIELDS: Name: Enter a name of the extension being created. Example: John Doe. E-mail: Enter the e-mail address associated with this extension. This e-mail address will receive all system notification messages.
Page 7
Registering ATA STEP ONE: Electricity and Ethernet. - The Grandstream HT-386 needs electricity. Plug the adapter into its jack then connect it to the electricity network. - Connect ethernet port to a hub, router or switch as to access LAN.
Page 8
IP address 2. Hit "Enter" on your keyboard. STEP FOUR: Configuring Grandstream HT-386. 1. Login to the Grandstream HT-386 web interface. The factory default password is lower case "admin". 2. Click on "FXS PORT1" link. 3. Enter following details into the respective fields.
Page 9
Other "options" or "fields" should be left blank or as is by default, they have no importance for registering Grandstream HT-386 to PBXware. 4. Navigate down and click on the "Update" button. 5. Click on the "Reboot" button. The Grandstream HT-386 will reboot for changes to take effect.
- Conclusion: If everything is done as above described you should have successfully registered your Grandstream HT-386 to PBXware. Dial *123 to verify registration. - For further information, please contact the manufacturer or check their web site www.grandstream.com. Auto Provisioning UAD Settings STEP ONE: PBXware IP address.
Page 11
STEP THREE: UAD status. 1. Make sure the UAD is enabled. To check the UAD status navigate to "Settings:UAD", and click on the "edit" icon corresponding to "Grandstream HT-386".
Page 12
2. Make sure "Status" is set to "active", "Auto provisioning" is set to "No" and "DHCP" is set to "Yes".
Page 13
STEP ONE: Add Extension. 1. Navigate to "Extensions". Click on "Add Extension". 2. The standard options window will be shown below. 3. Select Grandstream HT-386 from "UAD" select box. 4. Select Location: "Local" or "Remote". Note: -"Local" is for all extension registered on LAN.
Page 14
Enter a name of the extension being created. Example: John Doe. E-mail: Enter the e-mail address associated with this extension. This e-mail address will receive all system notification messages. Example: john@domain.com Auto provisioning: Set to "Yes". MAC Address: Grandstream HT-386 MAC address. Example: 001646f5f797 an example with details filled in...
Page 15
Registering ATA STEP ONE: Electricity and Ethernet. - The Grandstream HT-386 needs electricity. Plug the adapter into its jack then connect it to the electricity network. - Connect ethernet port to a hub, router or switch as to access LAN.
Page 16
Example: http://192.168.1.101 an example with IP address 2. Hit "Enter" on your keyboard. STEP FOUR: Configuring TFTP server. 1. Login to the Grandstream HT-386 Web interface. The factory default password is lower case "admin". 2. Click on "BASIC SETTINGS" link.
Page 17
- Select "statically configured as" button. - IP Address: enter an IP. Example: 192.168.1.111 - Please make sure that the Grandstream HT-386 static IP do not conflict with an IP of another device on the same network. 4. Click on the "Update" button to save changes.
Page 18
7. Navigate down and click on "Update" button. 8. Click on the "Reboot" button. The Grandstream HT-386 will reboot for changes to take effect. - Conclusion: If everything is done as above described you should have successfully registered *123 your Grandstream HT-386 to PBXware.
Page 19
the system to which they are directly connected. - Router = A device that forwards data packets from one local area network (LAN) or wide area network (WAN) to another. - Switch = Network device that selects a path or circuit for sending a unit of data to its next destination.
