Summary of Contents for Westward Supa-Lite 48UJ78

  • Page 1 Operating Instructions & Parts Manual Supa-Lite Pistol Grease Model 48UJ78 and 48UJ79...
  • Page 2 COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE! RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. PLEASE REFER TO BACK COVER FOR INFORMATION REGARDING WESTWARD’S WARRANTY AND OTHER IMPORTANT INFORMATION. Model #: ___________________ Serial #: ___________________ Purch. Date: _______________ Printed in India Version 03/ 2016 ©...
  • Page 3: Before You Begin

    BEFORE YOU BEGIN Tools needed: • Spanner (14mm) Protection equipment (PPE) requirements: • Goggles, Safety Gloves, Safety Helmet, and Safety Boots UNPACkiNG Steps: Wear cotton gloves before unpacking. Use small knife or scissor to cut tapes on the carton for opening/ unpacking.
  • Page 4: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS Grease or empty cartridge in the barrel is under pressure from the internal spring. Be extremely careful when removing either end of the barrel. Connections of the hose must be secured tightly to avoid any oil leakage. Always before refilling make sure that the plunger rod is completely outward and is in locked position Always use safety goggles when using the grease...
  • Page 5 ASSEMBLY iNSTRUCTiONS Selection of rigid extension or flexible hose Rigid extension can be used in easily accessible grease fittings and it also makes greasing a one hand operation whereas the flexible hose is designed to access inaccessible grease fittings, it requires two hands for its operation one to press the trigger and the other hand to reach out for the grease fitting.
  • Page 6 OPERATING INSTRUCTIONS Cartridge Loading Bulk Loading Remove the gun head by rotating it in counter-clockwise direction. Pull the Plunger Rod Handle all the way Fill the barrel with grease using a scoop back and lock it. Remove the plastic cap from the When the barrel is completely filled with cartridge and insert the open end of the grease, shake the grease gun barrel to...
  • Page 7: Troubleshooting

    TROUBLESHOOTING Symptom Possible Cause(s) Corrective Action Grease gun pumps Air is trapped in Priming is required,refer little or no grease grease “Prime the grease gun” section. Blocked extension/ Remove the extension/ hose hose and operate the grease gun. If the gun dispenses grease then the gun is fine and you need to either clean the...
  • Page 8: Maintenance

    Maintenance Grease gun and extension/hose should be kept clean and checked for damage before each use. Greasing a grease fitting / nipple The grease coupler provided at the end of the grease gun extension has a jaw type construction. The coupler jaws snaps on to a grease fitting and maintains a tight fit. When connecting the coupler to the grease fitting, press the coupler straight onto the grease fitting to form a snug fit.
  • Page 9: Parts Illustration

    parts ILLUstratION For Repair Parts, call 1-800-323-0620 24 hours a day – 365 days a year Please provide following information: -Model number -Serial number (if any) -Part description and number as shown in parts list...
  • Page 10: Parts List

    parts list Parts Description Qty. Barrel Assembly Fixed Handle Key Ring Torsion Spring Movable Handle Rivet U-Clip Rivet O-Ring Block Nut Rivet Piston Head Steel Ball Non Return Spring Rubber Washer Grease Straight Pipe Hydraulic Coupler Flexible Hose...
  • Page 11 Westward One-Year Limited Warranty. You may be required to send the product in for inspection at your cost. You can follow up on the progress of inspections and corrections in the same ways.
