- Page 1 Keysight N9010B EXA and N9020B MXA Signal Analyzers N9048B PXE EMI Receiver Option YAS Y-Axis Screen Video Out Installation Note...
- Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 Option YAS Installation Kit Option YAS Installation Kit Products Affected: N9010B EXA Signal Analyzer N9020B MXA Signal Analyzer N9048B PXE EMI Receiver Serial Numbers: Options To Be Performed By: (X) Keysight Service Center (X) Personnel Qualified by Keysight (X) Customer Estimated Installation Time: 0.5 Hours...
- Page 4 Option YAS Installation Kit Introduction This kit contains all of the instructions required to install Option YAS on Keysight EXA and MXA signal analyzers and PXE EMI receivers. Option YAS enables the ANALOG OUT port to provide a Y-Axis screen video output.
-
Page 5: Installation Procedure Over Usb
Option YAS Installation Kit Contents Quantity Description Keysight Part Number Installation Note This note Option Upgrade Entitlement Certificate 5964-5178 Tools Required for Installation — Personal computer with internet access and USB port — USB storage device with >2GB free memory Tools Required for Manual Operation Verification —... - Page 6 USB Storage Device Configuration Menu 7. The signal analyzer will automatically consume the License File. (This may take a few minutes) When the License File is consumed the Keysight License Manager will display a “Successful License Installation” message similar to the one shown in...
- Page 7 Option YAS Installation Kit Manually Verify Operation 1. Preset X-Series analyzer. Assure mode is Spectrum Analyzer. 2. Display the 50 MHz calibrator signal. Press Input/Output, RF Calibrator, 50 MHz. Press FREQ, Center Frequency, key in 50 MHz. Press Span, Zero Span. You should see a flat line across the display at −25 dBm.
- Page 8 For assistance, contact your nearest Keysight Technologies Sales and Service Office. To find your local Keysight office access the following URL, or if in the United States, call the following telephone number: http://www.keysight.com/find/assist...
- Page 9 This information is subject to change without notice. © Keysight Technologies 2016-2018 Edition 1, October 2018 N9020-90272 www.keysight.com...
