- Page 1 2018-11-09 WB-10 SpecificationsandOperationManual Model :WB-10 1stversion Edition Month Year Feb. 2018 ...
- Page 2 2018-11-09 WB-10 Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 3 2018-11-09 WB-10 TableofContent 1. General Layout ........................1 2. Feature ............................ 2 3. Operation Condition ......................2 4. External Connector ......................3 4.1 PowerConnector ........................ 3 4.2 EthernetConnetor ......................3 5. Physical layoutofElectricalConnection ................3...
- Page 4 2018-11-09 WB-10 1. GeneralLayout R&DDept. ©2018SHANGHAITERAOKAELECTRONICCO.,LTD. 1of 3...
- Page 5 2018-11-09 WB-10 2. Feature NetworkParameters Wirelessstandard:IEEE802.11n,g,b Networkstandard LAN standard: IEEE802.3, IEEE802.3u IEEE802.11n: 150MbpsMax; Wirelesstransmission rate IEEE802.11g: 54MbpsMax; IEEE802.11b: 11MbpsMax Numberof channels 1~11 FrequencyRange 2.4000~2.4835G Transmitpower 15dBm Antenna Antennatype External antenna Function Parameters ...
- Page 6 2018-11-09 WB-10 4. ExternalConnector 4.1 PowerConnector 1 xDC JACK 4.2 Ethernet Connetor 1 xRJ45: Connectwith PCorDIGIscale. 5. Physical layoutofElectrical Connection ...
