2B. Removing the Magazine and Loading (option)
The barrel blocking device must be installed (see page 4) and the trigger safety in Safe mode
(see page 6).
Two 20 round Magazines are provided with the marker.
a. To remove the Magazine, push in the Magazine Release
button and the Magazine ejects out the bottom of the
Magazine Well (Mag Well).
b. Use tabs on the side of the Carrier to pull it down until it locks into place at the
bottom of the Magazine.
c. Keep the Magazine vertical, and insert one paintball at a time into the top of the
Magazine until full. Paintballs in the Magazine are not under pressure until the
Magazine is inserted into the Mag Well.
d. To insert a loaded Magazine into the Mag Well, slide the Magazine into the grip until
you hear it lock into place.

3. Firing Your Marker

a. Go to a designated firing area, remove the barrel blocking device, and move the
Trigger Safety to Fire mode (see page 6).
b. Point your marker in a safe direction and pull the trigger to fire the marker.
c. When finished firing the marker, put the Trigger Safety in Safe mode (page 6) and
install the barrel blocking device (page 4).

4. Velocity Adjustment

Each time you play paintball, check the velocity of your paintball marker with a chronograph
(an instrument for measuring velocity) prior to playing paintball. Verify that the marker's
velocity is set below 300 feet per second (or less if required by the playing field).
To adjust the marker's velocity, use the included 3/16" hex key. The velocity adjustment screw
is located on left side receiver. To
reduce the velocity , turn the screw
inward or clockwise. To increase
the velocity, turn the screw out or
counterclockwise. Do not remove the
velocity screw.
Quick Start Guide Rev. 12/19
Velocity Adjustment Screw Location
Use a 3/16" hex key to adjust the velocity.
E
N
G
L
I
Magazine
S
Release
H
9
