be longer than usual. Because of the variances in cylinder pin valve parts, each cylinder
varies slightly on exactly how far it has to be turned). Turn the cylinder counterclockwise
a little further and repeat this step until the marker does not fire. Only then remove the
air/CO2 supply cylinder.
NOTE: If during this step, you turned the air/CO2 supply cylinder and it began to leak before
you pulled the trigger, the cylinder O-ring should be checked for damage before any re-
assembly.
6. After the air/CO2 supply cylinder is removed, again point and fire the marker in a safe
direction to verify the marker is completely discharged of gas.
7. Move the Trigger Safety to the Safe mode (see page 6) and install the barrel blocking
device (see page 4).

Converting from Hopper Fed to Magazine Fed

1. Replace the Hopper Feed Tube with the Mag Fed Cover Plate (85). This Cover
Plate contains the Ball Latch (80). The Ball Latch can be removed for replacement.
The Mag Fed Ball Latch is different from the Loader Fed Ball Latch. They are not
interchangeable. The Ball Latch Retaining Plate (86) holds the Ball Latch in place.
2. The Cover Plate is secured by Screw (52).
3. Remove the
Lower Grip Frame/Guard
described in step 3 under Disassembly.
4. Install the
Magwell & Guard
hooked part of the trigger guard into the grip,
and rotate the assembly up to the marker.
Secure to the marker with
5. When the Magazine is in the Magwell, it is
released by the
(87) for reloading. The release is spring-assisted
so it quickly ejects the Magazine from the magazine well.

Loading the Mag Fed Magazine

Loading instructions are molded into the side of the magazines.
1. It is important to wind up the spring by rotating the knob on the magazine in the
clockwise direction.
2. Paintballs may be inserted past the magazine ball catch, but if paintballs are fragile, we
recommend retracting the ball catch release.
3. The Magazines hold 20 paintballs, but loading 19 is best. If magazines are to be
carried in a battle pack, this ensures the 19 paintballs are not under any compression,
compression may cause flat spots on the paintballs.

Installing Marker Options

Ball Latch

Replace the Ball Latch by pushing up a hex key through
the hole in the
Lower Grip Frame/Guard
Quick Start Guide Rev. 12/19
(87). Place the
(49).
Screws
Magazine Release Button
(82) as
(82).
E
N
G
L
I
S
H
