- Page 1 SmartDC Installation Guide...
-
Page 2: Table Of Contents
Table of contents Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Specifications . -
Page 3: Security
Security IMPORTANT SAFETY INSTRUCTIONS-PLEASE DO NOT DISCARD THESE INSTRUCTIONS Carefully read this guide before installing the EVSE . 1 . This station was designed to be ground-based and installed on a non combustible surface . 2 . Make sure with local authorities that the location where the EVSE is to be installed is free from underground pipelines or electrical equipment, otherwise you might inflict yourself serious injuries . -
Page 4: Specifications
Specifications Model: SmartDC Revision: V2 Company Info: AddEnergie Technologies Inc . Document revision number: V05-2017-04-10 ©2017 AddÉnergie Technologies Inc . All Rights Reserved . This document is protected by copyright laws of many countries and should not be modified, reproduced or distributed without the prior written consent of AddÉnergie Technologies . -
Page 5: Dimensions
Dimensions 200cm 200 cm 79po 79" 83cm 83 cm 119cm 119 cm 33po 47po 33" 47" 2017 ADDÉNERGIE TECHNOLOGIES INC. ALL RIGHTS RESERVED. Information and Specifications Contained in this Document are Subject to Change, Amendments, and Additions at any Time, Without Notice... -
Page 6: Exterior Preview Of The Station
Exterior Preview of the Station A: Locking door handle B: Start button C: Stop button D: Display E: RFID card reader F: SAE J1772 Combo connector G: CHAdeMO connector H: Base I: Air intake J: Air outtake 2017 ADDÉNERGIE TECHNOLOGIES INC. ALL RIGHTS RESERVED. Information and Specifications Contained in this Document are Subject to Change, Amendments, and Additions at any Time, Without Notice... -
Page 7: Interior Preview Of The Station
Interior Preview of the Station A: Power cable access B: Three phase and neutral terminals C: Door switch D: AC/DC conversion modules E: Grounding terminal 2017 ADDÉNERGIE TECHNOLOGIES INC. ALL RIGHTS RESERVED. Information and Specifications Contained in this Document are Subject to Change, Amendments, and Additions at any Time, Without Notice... -
Page 8: Typical Installation
A: Electrical equipment cabinet (metering, protection and distribution) B: Power cable (three-phase 480Y/277 Volts @ 100A + NEUTRAL + GROUND) C: SmartDC Station D: Master disconnect switch (must be visible from the station) E: Parking space for the electric vehicle... -
Page 9: Site Preparation
Site Preparation 2'3" 2'7" 2'3" 68,6 cm 78,4 cm 68,6 cm 9" / 22,8 cm 1'11" 58,4 cm 6" / 15,2 cm 6'0" 182,9 cm Optimal output zone for the Zone optimale de sortie Zone optimale de sortie du conduit électrique electric conduit Station’s perimeter Périmètre de la Borne... -
Page 10: Installing The Base Onto A Concrete Floor Slab
Base Installation on Concrete Slab Back 34,3 cm 34,3 cm 28,6 mm 7,6 mm 15,2 mm 52,7 cm 58,4 cm 5,1 cm Front side 78,7 cm 10,2 cm / 15,2 cm Front 15,2 cm 1 . It is recommended to use stainless steel ¼ inch (6,4 mm) concrete wedge anchors (not included) . 2 . -
Page 11: Installing The Station Onto The Base
Installing the Station onto the Base Power cable access plate 1 . Remove the access plate to allow the passage of the power cable . 2 . Place the station onto its base, making sure to pass the power cable through the access hole . 3 . -
Page 12: Electrical Connections To The Station
Electrical Connections to the Station 1 . Connect the three conductors into the three-phase power terminal . 2 . Connect the NEUTRAL conductor into the neutral terminal . 3 . Connect the GROUND into the grounding terminal . 2017 ADDÉNERGIE TECHNOLOGIES INC. ALL RIGHTS RESERVED. Information and Specifications Contained in this Document are Subject to Change, Amendments, and Additions at any Time, Without Notice... -
Page 13: Station Start-Up
Station Start-up Before turning the station on: 1 . The electrician must ensure that the electrical installation conforms to the applicable electric code . 2 . The circuit breakers inside the charging station must be in the “ON” position . As the station is being turned on: 1 . -
Page 14: Care And Maintenance Of The Station
Care and Maintenance of the Station THIS STATION REQUIRES YEARLY MAINTENANCE TO ENSURE PROPER OPERATION. MAINTENANCE MUST BE PERFORMED BY ADDÉNERGIE. It consists of: 1 . Cleaning or replacing the cooling system filters . *It is important to maintain proper airflow inside the station to adequately cool the power modules . 2 . - Page 15 AddÉnergie Technologies Inc . Eastern office: 2327, Versant Nord Boulevard, office 120, Québec (QC) G1N 4C2 CANADA Central office: 7420 Airport Road, Mississauga (ON) L4T 4E5 CANADA Contact Us T . 1 877 505-2674 F . 855 505-2674 info@addenergie .ca addenergie .ca...
