- Page 1 SmartTWO Installation Guide...
- Page 2 IMPORTANT Split Phase 120/240 VAC Supply or 3 phase 120/208 VAC C (must be protected by a 40 A fuse or circuit breaker) Both lines must have 120V between ground. Voltage supply must be grounded. Require 2 lines and 1 ground connection. Neutral is not used. (Refer to Figure 1 and Figure 2). Maximum output power: 7.2 kW @ 240 VAC or 6.3 KW @ 208 VAC Built-in protection against overvoltage conditions and leakage current to ground Connect the power supply of the EVSE with caliber 2 to 8 copper or aluminium conductors...
-
Page 3: Table Of Contents
Table of Contents Specifications ........4 Maintenance and Safety ......5 Configurations . -
Page 4: Specifications
Specifications Model: SmartTWO Revision: V4 Company Info: AddEnergie Technologies Inc. Document revision number: V20-2019-04-03 © 2019 AddÉnergie Technologies Inc. All Rights Reserved. AddÉnergie Technologies Inc. reserves the right to alter product offerings and specifications at any time without notice and is not responsible for typographical or graphical errors that may appear in this document. -
Page 5: Maintenance And Safety
Maintenance and Safety IMPORTANT SAFETY INSTRUCTIONS - PLEASE DO NOT DISCARD THESE INSTRUCTIONS Carefully read this guide before installing the EVSE 1. This EVSE was designed to be ground-based, wall-mounted or pole-mounted. 1.1. For the pedestal version, it must be mounted on a non-combustible surface. 1.2. -
Page 6: Configurations
Configurations Dimensions Pedestal EVSE Pole-mounted EVSE Leave a minimum of 7,6 cm (3’’) Leave a minimum of 7,6 cm (3’’) on top of the main structure 20cm on top of the main structure to insert the EVSE’s head. to insert the EVSE’s head. 20cm 102cm 154cm... -
Page 7: Pedestal
Pedestal Site preparation ANCHOR The installer can use a prefabricated anchor offered by AddÉnergie (part number: S2-V2- ACCSP-01-03) or make his own using 12” long ½” threaded rods spaced according to the pattern shown on left. 85.7 mm (3.375’’) 85.7 mm (3.375’’) Fig. - Page 8 Pedestal Anchor positioning Piédestal simple, face parallèle Piédestal simple, face parallèle Piédestal double Piédestal double Piédestal quadruple Piédestal quadruple Piédestal simple, face à angle Piédestal simple, face à angle Single pedestal, straight facing Single pedestal, straight facing Double pedestal Double pedestal Quad pedestal Quad pedestal Single pedestal, angle facing...
- Page 9 Pedestal Single base installation Description Qté INSTRUCTIONS: Structure principale Panneau frontal • Install the main structure over the concrete base. Couvercle du bornier Cache-base Make sure to maintain a minimum of 3 cm (1.125”) Écrou Rondelle between the bottom of the structure and the top of Lock washer the base.
- Page 10 Pedestal Double & quadruple base installation INSTRUCTIONS: • Identify which sides of the main structures Piédestal double / Double pedestal Double pedestal must be assembled side to side and remove their corresponding bolts and joining plates. • Place the main structures one against the other and join them together with the 2 bolts you just removed.
- Page 11 Pedestal Double & quadruple base installation For double or quadruple mounting with panel holder (part number: S2-V2- ACCSPSM-01-02), add spacers (part number: S2-V2-ACCSPSM-01-05) between the main structures. Utiliser des boulons plus longs 3.8 cm (1.5’’) Use longer bolts, 3.8 cm (1.5’’) ©...
-
Page 12: Wall Mount
Wall Mount Single unit installation INSTRUCTIONS: Patron de perçage: Description Qté Drilling pattern: • Make sure that the available height is a Structure principale Panneau frontal minimum of 216 cm (85”) Couvercle du bornier 8.3 cm Description • If the wall requires that anchors to be pre- (3.25’’) Main Structure Front Panel... -
Page 13: Connection
Wall Mount Double unit installation For double mounting with panel holder (part number: S2-V2-ACCSPSM-01-02), add spacers (part number: S2-V2-ACCSPSM-01-05) between the main structures. Utiliser des boulons plus longs 3.8 cm (1.5’’) Use longer bolts, 3.8 cm (1.5’’) © 2019 ADDÉNERGIE TECHNOLOGIES INC. ALL RIGHTS RESERVED Information and specifications contained in this document are subject to change, amendments and additions at any time, without notice... - Page 14 Wall Mount Double unit installation INSTRUCTIONS: • Identify which sides of the main structure must be assembled face to face and remove their corresponding bolts and screwed plates. • Place the main structures one against the other and join using the four (4) longest carriage bolts you just removed.
-
Page 15: Front Panel And Base Cover Installation
Electrical Connections Remove the block cover. Insert the wires from the bottom of the base and proceed with the connection as shown on the figure below for each EVSE. Piédestal Pedestal Mural Wall-mounted IMPORTANT Installation and maintenance of this EVSE must only be Input: 208/240VAC nominal, 60Hz, 30A performed by a certified electrician to ensure compliance Recommended tightening torque for the block bolts: 18 Nm. - Page 16 Front Panel & Base Cover Installation INSTRUCTIONS: 1. For a pedestal installation, insert base covers into each of the main structure down to the ground and fasten them with the provided hardware. 2. Slide the front panels into each of the main structures. 3.
-
Page 17: Station Heads Installation On The Bases
Station Head and Connector Installation Installation of the charging station head on its base 1. Unscrew the charging port holder 2. Remove the charging port and cable assembly 2.1 Dsconnect the three positions connector and the small black connector 2.2 Unscrew the two brackets 3. -
Page 18: Installation Of The Panel On The Charging Head
Installation of the Panel on the Charging Head • Slide the panel holder onto the charging station head as shown in the image on the left (at this stage, the panel holder is not attached to the head but simply clipped to it). •... -
Page 19: Preliminary Tests And Commissioning
Gateway according to the instructions described in the “Important” section, on page 2 of this guide. 4.2. Call AddEnergie for charger commissioning: 877-505-2674 © 2019 ADDÉNERGIE TECHNOLOGIES INC. ALL RIGHTS RESERVED Information and specifications contained in this document are subject to change, amendments and additions at any time, without notice... - Page 20 Installation or commissioning questions: (877) 505-2674 AddÉnergie Technologies Inc. Head office: 2800, Louis-Lumière Street, office 100, Québec (QC) G1P 0A4 CANADA Contact Us T. 1 877 505-2674 F. 855 505-2674 info@addenergie.ca addenergie.ca...
