DOREL ASIA
Lakeley Dresser
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
DA7253-1E (Espresso)
DA7253-1W (White)
(TAKEN FROM CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR ASSISTANCE
E-Mail: das@dorel.com
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETURN PRODUCT TO
E-MAIL:DAS@DOREL.COM
Model No:
UPC CODE:
0-65857-17022-1
0-65857-17023-8
DPCI#:
030-08-3330
030-08-3333
Lot number:
Advertisement
Table of Contents
Related Manuals for Dorel Baby Relax Lakeley
Summary of Contents for Dorel Baby Relax Lakeley
- Page 1 DOREL ASIA Model No: DA7253-1E (Espresso) DA7253-1W (White) Lakeley Dresser UPC CODE: 0-65857-17022-1 0-65857-17023-8 DPCI#: 030-08-3330 030-08-3333 Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact our customer service department.
-
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase. -
Page 3: Hardware List
Lakeley Dresser DA7253-1E / DA7253-1W HARDWARE LIST Ø8 X 30mm Ø6 X 20mm LARGE WOOD DOWEL SMALL WOOD DOWEL LARGE CAM LOCK 20 PCS 24 PCS 21 PCS LARGE CAM BOLT SMALL CAM LOCK SMALL CAM BOLT 21 PCS 24 PCS 24 PCS Ø3 X 15mm KNOB... -
Page 4: Parts List
Lakeley Dresser DA7253-1E / DA7253-1W PARTS LIST TOP PANEL LEFT SIDE PANEL RIGHT SIDE PANEL MIDDLE PANEL 1 PC 1 PC 1 PC 1 PC FRONT TOP RAIL FRONT BOTTOM RAIL BACK TOP RAIL BACK BOTTOM PANEL 1 PC 1 PC 1 PC 1 PC BACK TOP PANEL... - Page 5 Lakeley Dresser DA7253-1E / DA7253-1W PARTS LIST LEFT BOTTOM DRAWER FRONT RIGHT TOP DRAWER FRONT RIGHT MIDDLE DRAWER FRONT RIGHT BOTTOM DRAWER FRONT 1 PC 1 PC 1 PC 1 PC...
- Page 6 Lakeley Dresser DA7253-1E / DA7253-1W STEP 1 Insert large cam bolts (4) into front top rail (E), back top rail (G), front bottom rail (F) and back bottom panel (H) as shown.
- Page 7 Lakeley Dresser DA7253-1E / DA7253-1W STEP 2 Insert large wood dowels (1) into middle panel (D) as shown.
- Page 8 Lakeley Dresser DA7253-1E / DA7253-1W STEP 3 Insert large cam locks (3) into middle panel (D) as shown. Attach rails (E, F & G) and back bottom panel (H) to middle panel (D) as shown below. Secure rails (E, F & G) and back bottom panel (H) to middle panel (D) by rotating the large cam locks (3) on middle panel (D) 1/2 turn clockwise using a Phillips head screwdriver (not included).
- Page 9 Lakeley Dresser DA7253-1E / DA7253-1W STEP 4 Insert large wood dowels (1) and large cam bolts (4) into left side panel (B) and right side panel (C). Insert large cam locks (3) into rails (E,F,G) and back bottom panel (H) as shown. Attach left side panel (B), right side panel (C) and support panel (J) to the assembled unit as shown.
- Page 10 Lakeley Dresser DA7253-1E / DA7253-1W STEP 5 Insert large cam bolts (4) into top panel (A).
- Page 11 Lakeley Dresser DA7253-1E / DA7253-1W STEP 6 Insert large wood dowels (1) into left side panel (B), middle panel (D) and right side panel (C) as shown. Insert large cam locks (3) into side panels (B & C) and middle panel (D). Fasten top panel (A) to the assembled unit using screws (10) and by rotating large cam locks (3) 1/2-turn clockwise using a Phillips head screwdriver (not included).
- Page 12 Lakeley Dresser DA7253-1E / DA7253-1W STEP 7 Attach back top panel (I) to the assembled frame with round head screws (9). Use a Phillips head screwdriver (not included) to tighten screws.
- Page 13 Lakeley Dresser DA7253-1E / DA7253-1W STEP 8 Insert small cam bolts (6) and small wood dowels (2) into front drawer panel (R). Insert small cam locks (5) into left drawer sides (K) and right drawer sides (L). Attach drawer sides (K & L) to front drawer panel ( R). Secure the drawer sides by rotating small cam locks (5) 1/2-turn clockwise using a Phillips head screwdriver (not included).
- Page 14 Lakeley Dresser DA7253-1E / DA7253-1W STEP 9 Attach drawer backs (N) to drawer sides (K & L) with flat head screws (10). Use a Phillips head screwdriver (not included) to tighten the screws. Attach knobs (7) to front drawer panels (R) with bolts (8). Use a Phillips head screwdriver (not included) to tighten bolts.
- Page 15 Lakeley Dresser DA7253-1E / DA7253-1W STEP 10 Insert all drawers into the assembled unit.
- Page 16 If a part is missing or damaged, contact our customer service department. We will replace the part FREE of charge. NEED HELP! Tel #: 1-800-295-1980 CALL US FOR ASSISTANCE E-Mail: das@dorel.com 1-800-295-1980 Fax #: 514-353-7819 DO NOT RETURN PRODUCT TO S E-MAIL:DAS@DOREL.COM...
- Page 17 Furniture Wall Safety Strap SAFETY WALL MOUNTING BRACKET LONG SCREW SHORT SCREW STRAP 4 PCS 2 PCS 2 PCS 2 PCS TOOLS NECESSARY: RUBBER MALLET AND PHILLIPS SCREW DRIVER ARE NOT INCLUDED. NOTE: 3/8" DRILL BIT AND ELECTRIC DRILL ARE NOT PROVIDED. WARNING: WHEN UPRIGHT, IT IS POSSIBLE THAT THE FURNITURE MAY TIP OVER.
-
Page 18: Customer Service
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address: Street &...
