Assembly Manual

TWIN BED

CONTAINS

INFORMATION. PLEASE READ AND

KEEP FOR FUTURE REFERENCE.

DO NOT RETURN PRODUCT TO THE STORE.

If a part is missing or damaged, contact our customer service

department. We will replace the part FREE of charge.

01WM6108EC ESPRESSO

01WM6108WC

0-65857-16046-8 ESPRESSO

0-65857-16047-5

THIS INSTRUCTION BOOKLET

IMPORTANT SAFETY

(TAKEN FROM CARTON)

_______ / _______ / _______

Tel # : 1-800-295-1980

E-Mail: das@dorel.com

Fax #: 514-353-7819

Model No.:

WHITE

UPC CODE:

WHITE

NOTE:

Lot number:

Date of purchase:

Need help?

Do you have a question about the 01WM6108EC and is the answer not in the manual?

Questions and answers

Summary of Contents for Dorel 01WM6108EC

Page 1 Assembly Manual Model No.: 01WM6108EC ESPRESSO TWIN BED 01WM6108WC WHITE UPC CODE: 0-65857-16046-8 ESPRESSO 0-65857-16047-5 WHITE NOTE: THIS INSTRUCTION BOOKLET IMPORTANT SAFETY CONTAINS INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Distribution Canada warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.
Page 3 TWIN BED 01WM6108EC/01WM6108WC METAL PLATE 2 PCS...
Page 4 TWIN BED 01WM6108EC/01WM6108WC...
Page 5 TWIN BED 01WM6108EC/01WM6108WC PARTS LIST...
Page 6 TWIN BED 01WM6108EC/01WM6108WC STEP 1 Insert stoppers (10) and headboard slats (G) into each hole of the headboard bottom cross (F) and push down until firmly in place. Slide the headboard top cross (E) onto the headboard slats (G). Insert wood dowels (4) into the ends of top cross (E) and bottom cross (F).
Page 7 TWIN BED 01WM6108EC/01WM6108WC STEP 2 Attach side rails (J and K) to headboard posts (A and B) with joint connectors (1) and barrel nuts (2). Use Allen key (9) to tighten joint connectors (1).
Page 8 TWIN BED 01WM6108EC/01WM6108WC STEP 3 Attach the other side rails (J and K) to support posts (I) with joint connectors (5). Further secure the side rails using metal plates (7) and joint connectors (6) as shown below. Attach the side rails (J and K) to footboard posts (C and D) with joint connectors (1) and barrel nuts (2).
Page 9 TWIN BED 01WM6108EC/01WM6108WC STEP 4 Attach one slat (L) to side rails (J and K) as close to headboard as possible with flat head screws (8). Attach the meaining slats (L) to the side rails (J and K) with flat head screws (8) using space blocks (M) to space them out evenly.
Page 10 Headboard SIDE RAIL Headboard TWIN BED 01WM6108EC/01WM6108WC CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury.
Page 11 MODEL #: 01WM6108EC (Espresso) / 01WM6108WC (White) A B B B C B D Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
