Dorel Ameriwood 9151202WP Instruction Booklet

Hide thumbs

Advertisement

Quick Links

Download this manual
A Dorel Company
MERIWOOD
INDUSTRIES
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
Please Recycle
Recicle Por Favor
TM
0
29986 91513
9151202WP
9
DO NOT RETURN PRODUCT TO THE STORE
STOP
Individual stores do not stock parts.
Date of Purchase
___ / ___ / ___
If a part is missing or damaged, visit our website or call our toll-free
customer service line. We will gladly ship your replacement parts
FREE of charge.
Need Parts or Assistance?
WWW.AMERIWOOD.COM/PARTS
For prompt, reliable service please have your assembly manual ready.
Recommended # of people needed for assembly: 2
(however it is always better to have an extra hand.)
Estimated assembly time is 2 hours.
Spanish translations are located in the center of this manual.
Se localizan las traducciones españolas en el centro de este
manual.
or call toll free:
1-800-489-3351
B349151202WP0 0

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ameriwood 9151202WP and is the answer not in the manual?

Questions and answers

Related Manuals for Dorel Ameriwood 9151202WP

Summary of Contents for Dorel Ameriwood 9151202WP

  • Page 1 A Dorel Company 9151202WP MERIWOOD INDUSTRIES 29986 91513 DO NOT RETURN PRODUCT TO THE STORE STOP Individual stores do not stock parts. Date of Purchase ___ / ___ / ___ If a part is missing or damaged, visit our website or call our toll-free customer service line.
  • Page 3 Parts modesty panel 39118202101 left panel right partition left partition right panel desk top 39118202010 39118202040 39118202030 39118202021 39151202110 left apron left kick right kick left bottom right fixed shelf right bottom 39118202190 39118202170 39118202180 39118202140 39118202150 39118202160 left door 39118202280 front crown molding right apron...
  • Page 4 Parts left keyboard pencil drawer back keyboard drawer front 2 pencil drawer sides pencil drawer front drawer side 39118302320 39118202330 right door 39118302310 39118202300 39118202340 39118202291 right keyboard keyboard drawer back drawer side left file drawer side 39118202360 file drawer front right file drawer side keyboard drawer bottom 39118202350...
  • Page 5 Hardware 1-1/4" flat head screw 1" washer head screw 1/2" pan head 1-3/4" flat #A11600 #A12840 euro screw screw head screw qty: 8 qty: 8 #A15600 #A12210 #A13410 qty: 16 qty: 66 qty: 11 hinge #A60010 qty: 4 nail 7/16" flat head #4 x 1/2"...
  • Page 6 This illustration shows how the CAM fastening system works. Esta ilustracion muestra el sistem de fijacion del tornillo de cerradura. drawer slide #A56030 qty: 2 HARDWARE COMPARTMENT LAYOUT A12210 (X66) A15600 (X16) A80250 (X4) A22430 (X20) #8 X 1/2" pan drawer screw shelf support 12mm cam lock...
  • Page 7 -Insert four CAM LOCKS (1) into the RIGHT FIXED SHELF (N), LEFT BOTTOM (O), and RIGHT BOTTOM (P) as shown. Proper orientation of CAM LOCK Orientation propio del tornillo de cerradura x 12 B349151202WP00 7 /28...
  • Page 8 Insert two CAM LOCKS (1) and screw two CAM BOLTS (2) into the LEFT PANEL (A) as shown. Attach one LEFT CABINET MEMBER (22a) to the LEFT PANEL (A) with three SCREWS (15) as shown. Fasten one ANGLE BRACKET (18) with one SCREW (12) as shown in the detail. Proper orientation of CAM LOCK Orientation propio del tornillo de cerradura B349151202WP00...
  • Page 9 Attach one LEFT CABINET MEMBER (22a) to the LEFT PARTITION (C) with three SCREWS (15). Turn the panel over and attach one RIGHT CABINET MEMBER (22b) with three SCREWS (15). On the same side insert two CAM LOCKS (1), screw two CAM BOLTS (2) and attach one PLASTIC CATCH (3a) with two SCREWS (12).
  • Page 10 Insert two CAM LOCKS (1) and screw four CAM BOLTS (2) into the RIGHT PANEL (B). Seperate the EXTENSION SLIDE (21) by extending it until it stops, depress the plastic lever and pull apart. Complete this procedure for both slides. Attach slide to the RIGHT PANEL with three SCREWS (12).
  • Page 11 Attach one RIGHT CABINET MEMBER (22b) to the RIGHT PARTITION (D) with three SCREWS (15). Turn the panel over and attach one EXTENSION SLIDE (21) with three SCREWS (12). On the same surface insert two CAM LOCKS (1), screw in four CAM BOLTS (2), and attach one PLASTIC CATCH (3a) with two SCREWS (12). Fasten one ANGLE BRACKET (18) with one SCREW (12) as shown in the detail.
  • Page 12 Screw eight CAM BOLTS (2) into the DESK TOP (K). Attach the FRONT CROWN MOLDING (U) to the DESK TOP (K) with five ANGLE BRACKETS (18) and ten SCREWS (12). NOTE: If you use the optional hutch (model 9902202W), refer to the model 9902202W hutch assembly manual to attach the desk top to the hutch assembly.
  • Page 13 This step will require the assistance of a second person. Secure the LEFT PARTITION (C) and RIGHT PARTITION (D) to the MODESTY PANEL (J) with four SCREWS (13). If assembled correctly, there will be a 1" (2.5cm) spacing between the top edge of the partitions and the top edge of the modesty panel.
  • Page 14 Align the LEFT PANEL (A) and LEFT PARTITION (C) with the LEFT BOTTOM (O) so that the CAM BOLTS (2) insert into the CAM LOCKS (1). Turn the CAM LOCKS (1) clockwise to lock in place. Align the RIGHT PANEL (B) and RIGHT PARTITION (D) with the RIGHT BOTTOM (P) and RIGHT FIXED SHELF (N) so that the CAM BOLTS (2) insert into the CAM LOCKS (1).
  • Page 15 NOTE: IF YOU HAVE PURCHASED THE OPTIONAL HUTCH, DO NOT ASSEMBLE THIS STEP UNTIL THE HUTCH HAS BEEN ASSEMBLED. YOU WILL NEED TO FOLLOW THE DIRECTIONS IN THE MODEL 9902202WY ASSEMBLY MANUAL, (THERE ARE FOUR HOLES THAT MUST BE DRILLED THROUGH TO ATTACH THE DESK TOP (K) TO THE HUTCH PANELS).
  • Page 16 Attach the LEFT KICK (Q) to the LEFT PANEL (A), LEFT PARTITION (C), and LEFT BOTTOM (O) with three ANGLE BRACKETS (18) and four SCREWS (12). Attach the RIGHT KICK (R) to the RIGHT PANEL (B), RIGHT PARTITION (D), and RIGHT BOTTOM (P) with four angle brackets (18) and six SCREWS (12).
  • Page 17 With assistance of another person, carefully stand the unit upright. Position the LEFT BACK PANEL (RR) so the bottom edge of the back panel is even with the bottom edge of the LEFT BOTTOM (O), and equally spaced side to side. Fasten the LEFT BACK PANEL (RR) to the unit using eighteen NAILS (16). NOTE: When you begin to nail the back panel to the unit, make sure the unit is square with the back panel and nail straight through into the back edges of the unit.
  • Page 18 Attach one LEFT DRAWER RUNNER (22c) to the PENCIL DRAWER SIDE (EE) with two SCREWS (15) and two DRAWER BRACKETS (17) with two DRAWER SCREWS (9). Attach one RIGHT DRAWER RUNNER (22d) to the other PENCIL DRAWER SIDE (EE) with two SCREWS (15) and two DRAWER BRACKETS (17) with two DRAWER SCREWS (9).
  • Page 19 Attach the PENCIL DRAWER SIDES (EE) to the PENCIL DRAWER FRONT (DD) with four DRAWER SCREWS (9). Attach the LEFT and RIGHT FILE DRAWER SIDES (MM and NN) to the FILE DRAWER FRONT (LL) with four DRAWER SCREWS (9). Attach one CUP PULL (19) with two BOLTS (6) onto the PENCIL DRAWER FRONT (DD) and the FILE DRAWER FRONT (LL). Insert SHELF SUPPORTS (5) into each of the drawer fronts.
  • Page 20 Slide the PENCIL DRAWER BOTTOM (PP) down the grooves in the PENCIL DRAWER SIDES (EE) until it is tight against the PENCIL DRAWER FRONT (DD). Attach the PENCIL DRAWER BACK (FF) with four SCREWS (10). finished surface superficie terminada B349151202WP00 20 /28...
  • Page 21 Slide the FILE DRAWER BOTTOM (QQ) down the grooves in the FILE DRAWER SIDES (MM and NN) until it is tight against the FILE DRAWER FRONT (LL). Attach the FILE DRAWER BACK (OO) with four SCREWS (10). Press one FILE HOLDER (20) onto each of the file drawer sides. finished surface superficie terminada B349151202WP00...
  • Page 22 Attach one PLASTIC CATCH (3a) to the LEFT and RIGHT KEYBOARD DRAWER SIDES (HH and II) with two SCREWS (12) each. B349151202WP00 22 /28...
  • Page 23 Secure the LEFT and RIGHT KEYBOARD DRAWER SIDES (HH and II) and KEYBOARD DRAWER BACK (JJ) to the KEYBOARD DRAWER BOTTOM (KK) with seven SCREWS (13). finished surface superficie terminada B349151202WP00 23 /28...
  • Page 24 Align the KEYBOARD DRAWER FRONT (GG) with the KEYBOARD DRAWER BOTTOM (KK) and press the FLAP HINGE (7) fully into both parts before attaching with five SCREWS (14) each. *DO NOT OVER TIGHTEN SCREWS (14).* Attach two PLASTIC CATCHES (3b) to the KEYBOARD DRAWER FRONT (GG) with four SCREWS (12). Do not tighten SCREWS (12) into the KEYBOARD DRAWER FRONT (GG) until the PLASTIC CATCHES )3b) have been adjusted to close properly.
  • Page 25 Attach the LEFT and RIGHT DRAWER RUNNERS (22c and 22d) to the KEYBOARD DRAWER BOTTOM (KK) with three SCREWS (15) each. Attach one CUP PULL (19) to the KEYBOARD DRAWER FRONT (GG) with two BOLTS (6). B349151202WP00 25 /28...
  • Page 26 Attach one PLASTIC CATCH (3b) to each door with two SCREWS (12). Attach one HANDLE (19) to each door with two BOLTS (6). Secure each door to the corresponding end panel with two HINGES (8) and eight SCREWS (12). Hinges have slotted holes for final adjustment of the doors. x 20 B349151202WP00 26 /28...
  • Page 27 Insert two GROMMETS (4) into the DESK TOP (K) by pressing evenly on all edges until fully seated. Install the PENCIL DRAWER (DD) and KEYBOARD DRAWER (GG). Install the FILE DRAWER (LL) by aligning the EXTENSION SLIDE (21) members, making sure the bearing carrier is all the way to the front before fullly closing the drawer.

  • Page 28: Weight Limits

    Call our toll free number for any assistance you should need or visit our Weight Limits: website: 1-800-489-3351 www.Ameriwood.com/parts Clean the product with your favorite furniture polish and a soft cloth. DO NOT USE harsh chemicals or abrasive cleaners. Move your new furniture carefully with two people. Lift and carry the unit. Never push or drag the unit.
