Figure 38 Dns Network Window - Nokia 7368 ISAM ONT E-240W-A Product Manual

Configure an E-240W-A indoor ONT
Procedure 22
1
Figure 38
Table 24
2
94
Release 06.00.00h | January 2019 | Edition 08
DNS configuration
Select Network > DNS from the top-level menu in the EPON Home Gateway window, as
shown in Figure 38.
DNS network window
Table 24 describes the fields in the DNS network window.
DNS network parameters
Field Description
DNS Proxy Select the Enabled checkbox to enable DNS proxy
Domain Name Domain name
IPv4 Address Domain IP address
Origin Domain Origin domain name
New Domain New domain name
Select the Enabled checkbox and click Save to enable DNS proxy.
3FE-46974-AAAA-TCZZA
7368 ISAM ONT E-240W-A Product Guide
Issue: 01
