B.Y.O.C.
Analog Chorus
Build Instructions.
If your kit contains a bezel mounted LED please use these instructions:
http://buildyourownclone.com/chorusinstructionsV1.pdf
page 2 - 3..............................................Parts Checklist
page 4 - 8..............................................Populating the Circuit Board
pages 9 - 10..........................................Assembly
page 11.................................................Wiring
pages 12 - 13.........................................Installing LED and mounting PCB
