- Page 1 INSTRUCTION BOOKLET ι ELECTRIC OVEN TBF 690 Please read this instruction booklet before using the appliance...
-
Page 2: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the oven. If you need assistance, contact our Customer Care Department on 08705 950950 Installation • When using other electrical appliances, ensure the • This oven must be installed by qualified personnel to the relevant British Standards. -
Page 3: Table Of Contents
Contents For the User For the Installer Important Safety Information Technical Data Description of the Oven Installation Controls Electrical Connection Before the First Use Building In Electronic Programmer Using the Oven Hints and Tips The Fan Oven Cooking Chart - Fan Oven Grilling Defrosting Cleaning the Oven... -
Page 4: Description Of The Oven
Description of the Oven 1. Control panel 7. Air Vents for Cooling Fan 2. Oven Control Function Knob 8. Grill 3. Electronic Programmer 9. Oven Light 4. Thermostat Control Knob 10.Oven Fan 5. Mains on Light 11. Rating Plate 6. Thermostat Control Light Oven accessories Grill Pan Grid... -
Page 5: Controls
Controls Push-Pull control knobs Some models are provided with push-pull control knobs (Fig. 1). These knobs can be completely sunken inside the control panel when the oven is not working. Oven Function Control Knob The oven is off Oven light - The oven light will be on without any cooking function Inner grill element only - Can be used for grilling... -
Page 6: Before The First Use
The cooling fan The cooling fan operates during cooking. Air is expelled through vents between the oven door and the control panel, as shown in the diagram. The cooling fan may run on after the oven is switched off to keep the controls cool. This is quite normal. Before the First Use Remove all packaging, both inside and outside the oven, before using the oven. -
Page 7: Electronic Programmer
Electronic Programmer 1. Push button for selecting a function 2. Decreasing control button “ ” 3. Increasing control button “ ” 4. Display 5. “Cooking Duration” pilot lamp 6. “End of cooking” pilot lamp 7. “Minute minder” pilot lamp 8. “Time of day” pilot lamp The oven will only work if the time of day has been set. - Page 8 “End of cooking” function With this function, you can set the oven to switch off automatically when a programmed end of cooking time is over. Place food in the oven, select a cooking function and adjust the cooking temperature. Press button repeatedly to select the “End of cooking”...
-
Page 9: Using The Oven
Using the Oven Always cook with the oven door closed. Stand clear when opening the drop down oven door. Do not allow it to fall open - support the door using the door handle, until it is fully open. The oven has four shelf levels, and is supplied with two shelves. -
Page 10: The Fan Oven
The Fan Oven The air inside the oven is heated by the element around the fan situated behind the back panel. The fan circulates hot air to maintain an even temperature inside the oven. The advantage of cooking with this function is energy saving through: Faster Preheating As the fan oven quickly reaches temperature, it is... -
Page 11: Cooking Chart- Fan Oven
Cooking Chart- Fan Oven Cooking times in the tables do not include pre-heating. It is necessary to pre-heat the oven for about 10 minutes before cooking. Cooking Level time cooking TYPE OF DISH NOTES temperature (°C) minutes CAKES Whisked recipes 2 (1 and 3)* 45 ~ 60 In cake mould... -
Page 12: Grilling
Grilling Hints and Tips Grilling must be carried out with the oven door closed. Most foods should be placed on the grid in the grill The grill pan handles must be removed from pan to allow maximum circulation of air and to lift the the pan during grilling. -
Page 13: Defrosting
How to Use the Thermal Grill Hints and Tips Thermal grilling offers an alternative method of cooking Prepare foods in the same way as for conventional grilling. food items normally associated with conventional grilling. Brush lean meats and fish lightly with a little oil or butter The grill element and the oven fan operate alternately, to keep them moist during cooking. -
Page 14: Cleaning The Oven
Cleaning the Oven Before cleaning always allow the cooling fan to Oven Shelves and Shelf Supports cool the oven down before switching off at the electricity supply. Clean the oven shelf support before This appliance cannot be cleaned with steam or proceeding to the catalytic cleaning of the with a steam cleaning machine. -
Page 15: Care Of Catalytic Liners
Care of catalytic liners Cooking to reduce soilage Catalytic liners (except for the oven base) destroy splashes of food and fats when the oven temperature is Cook at the recommended temperatures. Higher raised to around 220°C. temperatures during roasting will increase soilage. Try To aid this process it is a good idea to run the oven for an cooking to lower temperatures for an increased length of hour or two per week, without food, to ensure continued... -
Page 16: Replacing The Oven Light
Cleaning the hinged grill This model has been fitted with a hinged grill element to enable you to clean the roof of the oven easily. Before proceeding ensure the oven is cool and is disconnected from the electricity supply. 1) Undo the screws which hold the grill in place (see diagram 26). -
Page 17: Something Not Working
Something not working If the oven is not working correctly, please carry out the following checks, before contacting your local Service Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 18: Service And Spare Parts
For general enquiries concerning your Tricity Bendix ap- For Customer Service in the Republic of Ireland please pliance or for further information on Tricity Bendix prod- contact us at the address below: ucts, please contact our Customer Care Department by... -
Page 19: Guarantee Conditions
We, Tricity Bendix, undertake that if, within 12 months home subject to the following qualifications: of the date of the purchase, this Tricity Bendix appliance * The guarantee starts from the date you first or any part thereof is proved to be defective by any purchased your product. -
Page 20: Technical Data
Installation The oven must be installed according to the This oven must be installed by qualified instructions supplied. personnel to the relevant British Standards. Technical Data Heating elements rating Inner Grill element 1,650 W Dimensions of recess Full Grill element 2,450 W Height undertop: 593 mm;... -
Page 21: Building In
Building In Please ensure that when the oven is installed it is easily accessible for the engineer in the event of a breakdown. Building In The surround or cabinet into which the oven will be built must comply with these specifications: the dimensions must be as shown in the relevant diagrams;... - Page 22 EUROPEAN GUARANTEE This appliance is guaranteed by Electrolux in each of the countries listed below for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qualifications:- •...
- Page 24 TBF 690 0,79 kWh 0,78 kWh 43 min. 41 min. 1130 cm² 35691-4402 04/06...
