Tricity Bendix TBU750 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User
Manual
Oven
Model
TBU750

Advertisement

Table of Contents
loading

Related Manuals for Tricity Bendix TBU750

Summary of Contents for Tricity Bendix TBU750

  • Page 2: Table Of Contents

    The following symbols are used in this user manual: Important information concerning your personal safety and information on how to avoid damaging the appliance. General information and tips Environmental information Contents Important safety instructions Grilling chart Product description Oven cooking chart Before first use Roasting chart Grill and oven furniture...

  • Page 3: Important Safety Instructions

    Important safety instructions • This appliance is not intended for use by These warnings are provided in the interests of your safety. Ensure that you understand them children and other persons whose physical, all before installing or using the appliance. sensory or mental capabilities or lack of experience and knowledge prevents them Your safety is of paramount importance.

  • Page 4: Cleaning And Maintenance

    • Never line any part of the appliance with foil. • Never use steam or high pressure steam • Always stand back from the appliance when cleaners to clean the appliance. opening the oven door to allow any build up of steam or heat to release.

  • Page 5: Product Description

    Product description Grill / Top Oven Indicator Neons Electronic Timer Grill / Top Oven Function Selector Grill / Top Oven Temperature Selector Main Oven Temperature Selector Main Oven...

  • Page 6: Before First Use

    Before using the appliance Rating plate • This is situated on the front frame of the Always allow the cooling fan to cool the appliance and can be seen upon opening the appliance down before switching off at the door. Alternatively the rating plate may also wall prior to carrying out any cleaning or be found on the back or top of some models maintenance work.

  • Page 7: Grill And Oven Furniture

    Cookware • Baking trays, dishes etc., should not be placed directly against the grid covering the fan at the back of the oven. • Do not use baking trays larger than 30cm x 35cm (12” x 14”) as they will restrict the circulation of heat and may affect performance.

  • Page 8: Operation

    Operation The timer The increase and decrease control buttons operate slowly at first, and then more rapidly. They should be pressed separately. o set the countdown The 'Countdown' gives an audible reminder at the end of any period of cooking. This cooking period may be up to 2 hrs 30 mins.
  • Page 9 7. Release the buttons. The time of day will be The 'Countdown' indicator neon will continue displayed after 5 seconds. The 'Cook Time' to flash for a few seconds and then return to the time of day. and 'End Time' indicator neons will be illuminated.

  • Page 10: The Grill

    2. Release the buttons. The 'Cook Time' The grill indicator neon will flash and after 5 seconds return to the time of day. 3. Turn off the oven controls. CAUTION: Accessible parts may be hot when the grill is in use. Young children should be To return the appliance to manual kept away.

  • Page 11: The Top Oven

    To fit the grill pan handle The top oven To insert the handle, press the button on the The top oven is the smaller of the two ovens. It handle with the thumb and pivot the handle slightly is heated by elements in the top and bottom of upwards inserting the lip into the widest part of the the oven.

  • Page 12: The Main Oven

    To install a shelf, reverse the above steps. Using the fan oven Each shelf position has an upper and lower • Turn the main oven temperature control to support wire, ensure the shelf is placed between the required setting these two support wires. Things to note •...

  • Page 13: Defrost

    Using the defrost feature Defrost • Turn the main oven temperature control to This function defrosts most foods faster than the required setting. more conventional methods. It is particularly suitable for delicate frozen foods, which are to Things to note be served cold e.g.

  • Page 14: Oven Cooking Chart

    Oven cooking chart The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures to suit individual preferences and requirements. FAN OVEN TOP OVEN APPROX FOOD COOKING COOKING COOK TIME (m) TEMP °C TEMP °C Biscuits 180 - 190...
  • Page 15 Oven cooking chart continued FAN OVEN TOP OVEN APPROX FOOD COOKING COOKING COOK TIME (m) TEMP °C TEMP °C Choux Pastry 190 - 200 180 - 190 30 - 35 Éclairs / Profiteroles 170 - 180 170 - 180 20 - 30 Flaky Pastry 210 - 220 210 - 220...

  • Page 16: Roasting Chart

    Roasting chart MEAT TEMPERATURE COOKING TIME 20-35 minutes per ½kg (1lb) Beef/ Beef boned 160-180°C and 20-35 minutes over 25-35 minutes per ½kg (1lb) Mutton/Lamb 160-180°C and 25-35 minutes over 30-40 minutes per ½kg (1lb) Pork/Veal/Ham 160-180°C and 30-40 minutes over 15-20 minutes per ½kg (1lb) Chicken 160-180°C...

  • Page 17: Hints And Tips

    Hints and tips Hints and tips when using the grill Hints and tips when using the top • oven Most foods should be placed on the grid in • the grill pan to allow maximum circulation of Arrange the shelves in the required positions air and to lift the food out of the fats and before switching the oven on.
  • Page 18 Hints and tips when using fan Hints and tips when defrosting • cooking Place the frozen food in a single layer where • possible and turn it over half way through the Arrange the shelves in the required positions defrosting process. before switching the oven on.

  • Page 19: What To Do If

    What to do if… Please carry out the following checks on your In-guarantee customers should make sure that the checks have been made as the appliance before calling a Service Engineer. It may be that the problem is a simple one which engineer will make a charge if the fault is not you can solve yourself without the expense of a a mechanical or electrical breakdown.
  • Page 20 What to do if continued… PROBLEM POSSIBLE SOLUTION The oven is not cooking evenly. Check that the appliance is correctly installed and is level. Check that the recommended temperatures and shelf positions are being used. The oven light fails to illuminate. The oven light bulb may need replacing.

  • Page 21: Care And Cleaning

    Care and cleaning Removing and replacing the wirework runners Before cleaning always allow the appliance Remove all shelves to cool down before switching off at the and furniture from electricity supply. the oven. Hold the wirework Cleaning materials at the bottom, Before using any cleaning materials on your unclip from the appliance, check that they are suitable and that...

  • Page 22: Door Glass

    To remove the door glass Open the oven door slightly to gain access Aerosol cleaners must not come into contact to the two cross head screws on the top of with elements, the door seal, or any painted the oven door. finishes as this may cause damage.
  • Page 23 Replacing an oven light bulb The type of bulb required is a 300°C 25 watt If the door glass panel becomes chipped or small Edison Screw. has deep scratches the glass will be weakened and must be replaced to prevent the possibility of the panel shattering.

  • Page 24: Installation Instructions

    Installation • This appliance must be installed by a qualified electrician/competent person. Safety may be impaired if installation is not carried out in accordance with these instructions. • This appliance must be earthed. • Do not remove the screws from the earth tab extending from the oven mains terminal block.
  • Page 25 • Note: It is good practice to : The appliance socket switch should be • outside the cabinet but within 2m of the Fit an Earth Leakage Circuit Breaker to appliance to make it accessible to switch your house wiring. •...
  • Page 26 • • Fit the appliance mounting brackets using First remove retaining screw with pozidrive the two holes indicated to the adjacent screwdriver. cabinets. • Check that the mounting brackets are level. They can be adjusted if necessary by using the extra holes at the ends of the brackets. Once the brackets are level, drill a pilot •...
  • Page 27 • Clamp bare wires into the relevant terminal and check they are held by tugging each one in turn. • Clamp the mains cable securely ensuring Hook clamp 5mm of the outer insulation is inside the under here terminal block and that the wires are not taut but not so slack as to cause any Cable fouling.
  • Page 28 • Ensure the appliance is central and level. • When the appliance is fully housed, screw the stability screws (supplied with the appliance) into the underside of the worksurface in the positions indicated, taking care not to distort the trim. It is advisable to turn each screw alternatively to avoid damaging the trim.

  • Page 29: Technical Data

    Technical data Voltage: 230-240 Volts AC 50Hz Wattage: 5.0 - 5.5 kW Height: 720mm Width: 593mm Depth: (excluding handles and knobs) 550mm Weight 50kg This appliance complies with: European Council Directive 73/23/EEC, EMC Directive 89/336/EEC, CE Marking Directive 93/68/EEC, Energy Label Directive 2002/40/EC Environment At the end of the appliances After installation please dispose of the...

  • Page 30: Guarantee / Custormer Care

    Guarantee / Customer care Standard guarantee conditions Service and Spare Parts In the event of your appliance requiring service, or if We, Electrolux, undertake that if within 12 months of you wish to purchase spare parts, please contact the date of the purchase this Electrolux appliance or your local Service Force Centre by telephoning any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at...

  • Page 31: European Guarantee

    European guarantee • This appliance is guaranteed by Electrolux The appliance guarantee is personal to in each of the countries listed below for the the original purchaser of the appliance period specified in the appliance guarantee and cannot be transferred to another or otherwise by law.
  • Page 32 Great Britain +44 8705 929 929 Addington Way, Luton, Bedfordshire LU4 9QQ Hellas +30 23 10 56 19 70 4, Limnou Str., 54627 Thessaloniki Hrvatska +385 1 63 23 338 Slavonska avenija 3, 10000 Zagreb Ireland +353 1 40 90 753 Long Mile Road, Dublin 12 Italia +39 (0) 434 558500...
  • Page 33 Notes...
  • Page 34 Notes...
  • Page 35 Notes...
  • Page 36 www.electrolux.com www.tricity-bendix.co.uk 311801200...
