INSTALLATION INSTRUCTION
Please read this instruction carefully before installation .
Fits for most 17-42 inches Plasma, LCD and LED TVs .
Weight capacity: 20 kg(44 LBS) .
Thank you for purchase!We strive to provide products and services of exceptional quality.
We sincerely invite you to write an unbiased review. For parts missed or installation problems,
please contact us at telephone (626) 604-9048 (USA) Mon - Fri 10am - 6pm (Pacific time) or email
us by customerservice@mountingdream.com , so that we may solve the issue for you.
Max VESA: 200 X 200 mm/8X8"
MODEL : MD2268-S
(A9)

Advertisement

loading
Need help?

Need help?

Do you have a question about the MD2268-S and is the answer not in the manual?

Questions and answers

Related Manuals for Mounting Dream MD2268-S

Summary of Contents for Mounting Dream MD2268-S

  • Page 1 INSTALLATION INSTRUCTION Max VESA: 200 X 200 mm/8X8" MODEL : MD2268-S Please read this instruction carefully before installation . Fits for most 17-42 inches Plasma, LCD and LED TVs . Weight capacity: 20 kg(44 LBS) . Thank you for purchase!We strive to provide products and services of exceptional quality.
  • Page 2 Please do not use defective parts. Incorrect installation may result in product damage or body injury. Do not apply this product to any purpose not indicated by Mounting Dream. We shall bear no responsibility for any damage or injury resulted from incorrect installation, incorrect assembly or misuse.
  • Page 3 Before getting started, let's make sure this mount is perfect for you! Is your TV VESA equal to/greater than 75x75mm/3x3in and equal to/less than 200x200mm/8x8in? MAX:200mm/8" Yes --- Perfect! MAX: 200mm/8" No --- This mount is NOT compatible. Does your TV (including accessories) weigh more than 44 lbs (20kg)? NO --- Perfect! 44 lbs...
  • Page 4 For parts shortage or damage, please contact us directly by customerservice@mountingdream.com. Attention: New delivery will be timely arranged to replace missed or defective parts. Installation tools: 2M 2M Band tape Bubble level Stud finder Pencil Screwdriver Socket wrench 3/8" 5/32" Hammer Electrodrill 1/2"(13mm)

  • Page 5: Wall Mounting Hardware

    Wall mounting hardware ： -Lag bolt -3mm Allen key 4pcs TV mounting hardware ： a--M4X12 bolt b--M5X12 bolt c--M6X12 bolt d--M8X25 bolt 4 pcs 4 pcs 4 pcs 4 pcs e--M4X30 bolt f--M5X30 bolt g--M6X35 bolt h--M8X50 bolt 4 pcs 4 pcs 4 pcs 4 pcs...
  • Page 6 Step 1 Wall plate installation : Option 1 Wall plate installation in wood stud To avoid potential body injury or property damage: 1. Wall mount must be installed into wood stud's center, not drywall alone. 2. Drywall covering the wood stud must not exceed 16 mm (5/8 in.). 3.
  • Page 7 Option 2 Wall plate installation on concrete wall To avoid potential personal injury or property damage: 1. Make sure the logo on the wall plate is upward as the picture shows. 2. Solid concrete wall's thickness should be more than 100mm/4", and the wall must be CAUTION capable of supporting five times the weight of the TV plus the mount.
  • Page 8 Step 2 Select TV hardware (diameter / length / combination) Bolt diameter: hand thread bolts into threaded inserts on the back of TV to determine correct bolt diameter (M4, M5, M6, M8). Bolt length: verify adequate thread engagement with bolts or bolts/spacers combination.
  • Page 9 Step 3 Attach brackets to the back of the TV: ① For the TV with flat back, mount the brackets with bolt/washer/spacer combination. Tips: Make sure the ends of TV brackets with round holes are facing upward. Round hole is for upper VESA hole, and long slot hole for lower VESA hole.
  • Page 10 ② For TV with irregular back, mount the brackets with bolt/washer/spacer combination. (Spacers are highly recommended to be added, thus enlarge the space between TV and brackets for better functionality.) Tips: Make sure the ends of TV brackets with round holes are facing upward.
  • Page 11 Step 4 Hang the TV on the wall plate---Make sure the tilting angle is 0°: Please pre-tighten the inner side tilting bolts before hanging the TV on the wall plate. Hang the top hooks of the brackets over the top bar of the wall mount.

  • Page 12: Product Dimensions

    Step 6 To take down the TV from the mount, you may need to reduce the tilting angle to 0° by loosening the bolts with Allen key And loosen the safety screws . Then hold the TV upward to unlock the top hooks from the top bar. Product dimensions: 255mm 8°...
