Information about the device

Device description
The device BH30 permits the humidity regulation of
dehumidifiers or humidifiers between 20 % RH and 90 % RH.
For this purpose, install the device in-between consumer and
socket and set the desired humidity level.
With its integrated sensors the device measures the actual
relative humidity and regulates the connected terminal device
according to the desired target value.
The device comes with two operating modes, one for
dehumidification (activated when exceeding the target value)
and one for humidification (activated when falling below the
target value).
The currently achieved humidity level and the set operating
mode can be gathered from the display.
The device is equipped with an internal battery and a memory,
that way the settings are retained.
Device depiction
6
5
4
Re se t
3
No. Designation
1 Battery compartment
2 Mains plug
3 Connection for the terminal device (plug adapter)
4 Operating elements
5 Display
6 Operation indicator LED
4
Display and operating elements
16
15
14
13
No. Designation
7 Humidifier mode indication
8 Dehumidifier mode indication
9 SET indication
10 Indication of the target humidity value
11 Arrow down button
12 Reset button
13 Power button
1
14 Arrow up button
15 Indication of the current humidity level
16 RH indication
2
socket hygrostat BH30
7 8
Reset
9
10
11
12
