EINHELL TE-CD 12/1 Li-i Original Operating Instructions

Hide thumbs Also See for TE-CD 12/1 Li-i:
Table of Contents

Advertisement

Quick Links

Download this manual
GB
Original operating instructions
Cordless Impact Drill
7
Art.-Nr.: 42.572.37
Anl_TE_CD_12_1_Li_i_SPK7.indb 1
Anl_TE_CD_12_1_Li_i_SPK7.indb 1
TE-CD 12/1 Li-i
I.-Nr.: 11019
18.03.2019 08:16:18
18.03.2019 08:16:18

Advertisement

Table of Contents
loading

Related Manuals for EINHELL TE-CD 12/1 Li-i

Summary of Contents for EINHELL TE-CD 12/1 Li-i

  • Page 1 TE-CD 12/1 Li-i Original operating instructions Cordless Impact Drill Art.-Nr.: 42.572.37 I.-Nr.: 11019 Anl_TE_CD_12_1_Li_i_SPK7.indb 1 Anl_TE_CD_12_1_Li_i_SPK7.indb 1 18.03.2019 08:16:18 18.03.2019 08:16:18...
  • Page 2 - 2 - Anl_TE_CD_12_1_Li_i_SPK7.indb 2 Anl_TE_CD_12_1_Li_i_SPK7.indb 2 18.03.2019 08:17:03 18.03.2019 08:17:03...
  • Page 3 - 3 - Anl_TE_CD_12_1_Li_i_SPK7.indb 3 Anl_TE_CD_12_1_Li_i_SPK7.indb 3 18.03.2019 08:17:05 18.03.2019 08:17:05...
  • Page 4 - 4 - Anl_TE_CD_12_1_Li_i_SPK7.indb 4 Anl_TE_CD_12_1_Li_i_SPK7.indb 4 18.03.2019 08:17:09 18.03.2019 08:17:09...

  • Page 5: Table Of Contents

    Table of contents 1. Safety regulations 2. Layout and items supplied 3. Proper use 4. Technical data 5. Before using the equipment 6. Operation 7. Cleaning, maintenance and ordering spare parts 8. Disposal and recycling 9. Storage 10. Charger indicator - 5 - Anl_TE_CD_12_1_Li_i_SPK7.indb 5 Anl_TE_CD_12_1_Li_i_SPK7.indb 5...
  • Page 6 Danger! - Read the operating instructions to reduce the risk of injury Caution! Wear ear-muff s. The impact of noise can cause damage to hearing. Caution! Wear a breathing mask. Dust which is injurious to health can be generated when working on wood and other materials.

  • Page 7: Safety Regulations

    Danger! ment with care. • When using the equipment, a few safety pre- Remove the packaging material and any cautions must be observed to avoid injuries and packaging and/or transportation braces (if damage. Please read the complete operating available). • instructions and safety regulations with due care.

  • Page 8: Technical Data

    4. Technical data The specifi ed vibration value was established in accordance with a standardized testing method. It may change according to how the electric equip- Motor power supply: ....... 12 V DC ment is used and may exceed the specifi ed value Idling speed: ......0-400/0-1400 rpm in exceptional circumstances.

  • Page 9: Before Using The Equipment

    switched on but operates without load). 6.2 Torque setting (Fig. 4/Item 1) Caution! Only ever adjust the setting ring when 5. Before using the equipment the equipment is at a standstill. The cordless screwdriver is fi tted with a mechani- cal torque selector.

  • Page 10: Cleaning, Maintenance And Ordering Spare Parts

    6.5 On/Off switch (Fig. 5/Item 4) 6.10 Screwdriving Infi nitely variable speed control is possible with It is advisable to use self-centering screws (e.g. the On/Off switch. The further you push the Torx, cross recessed head) as these will enable switch, the higher the speed of the cordless you to work safely and reliably.

  • Page 11: Disposal And Recycling

    8. Disposal and recycling The equipment is supplied in packaging to pre- vent it from being damaged in transit. The raw materials in this packaging can be reused or recycled. The equipment and its accessories are made of various types of material, such as metal and plastic.

  • Page 12: Charger Indicator

    10. Charger indicator Indicator status Explanations and actions Red LED Green LED Off Flashing Ready for use The charger is connected to the mains and is ready for use; there is no battery pack in the charger Off Charging The charger is charging the battery pack in quick charge mode. Off...
  • Page 13 For EU countries only Never place any electric power tools in your household refuse. To comply with European Directive 2012/19/EC concerning old electric and electronic equipment and its implementation in national laws, old electric power tools have to be separated from other waste and disposed of in an environment-friendly fashion, e.g.
  • Page 14 Service information We have competent service partners in all countries named on the guarantee certifi cate whose contact details can also be found on the guarantee certifi cate. These partners will help you with all service re- quests such as repairs, spare and wearing part orders or the purchase of consumables. Please note that the following parts of this product are subject to normal or natural wear and that the following parts are therefore also required for use as consumables.
  • Page 15 Warranty certifi cate Dear Customer, All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event that your device develops a fault, please contact our service department at the address shown on this guarantee card.
  • Page 16 EÚ a noriem pre výrobok Lýsir uppfyllingu EU-reglna og annarra staðla vöru a cikkekhez az EU-irányvonal és Normák szerint a következő konformitást jelenti ki Cordless Impact Drill TE-CD 12/1 Li-i / Charger Power Charger 12 V (Einhell) 2014/29/EU 2006/42/EC Annex IV 2005/32/EC_2009/125/EC Notifi...
