MICROEDGE AND OMNICOM MOTHERBOARD REPLACEMENT
Introduction
Purpose
This FSB describes the steps for replacing the motherboard in the MicroEdge and Ominicom CNCs.

Materials and tools

No. 2 Phillips screwdriver
Kit 228559 contents
Part number
PCBS-0124
CABL-0277
CABL-0279
CABL-0281
806670
ii
Engage the emergency Stop button on the CNC and disconnect electrical
power before performing any maintenance.
Description
PCB: Motherboard
Cable: 20C/24C Motherboard power 10"
Cable: PS_ON, 24 ", Omnicom
Cable: PS_ON, 10.5", MicroEdge
FSB: MicroEdge and Omnicom Motherboard Replacement
WARNING
ELECTRIC SHOCK CAN KILL
Qty
1
1
1
1
1
Field Service Bulletin
