Keysight N9038A MXE EMI Receiver
Option YAS
Y-Axis Screen Video Out
Notice: This document contains references to Agilent.
Please note that Agilent's Test and Measurement busi-
ness has become Keysight Technologies. For more in-
formation, go to www.keysight.com.
Installation Note
Part Number N9038-90014
Printed in USA August 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N9038A and is the answer not in the manual?

Questions and answers

Related Manuals for Keysight N9038A

Summary of Contents for Keysight N9038A

  • Page 1 Option YAS Y-Axis Screen Video Out Notice: This document contains references to Agilent. Please note that Agilent’s Test and Measurement busi- ness has become Keysight Technologies. For more in- formation, go to www.keysight.com. Installation Note Part Number N9038-90014 Printed in USA August 2014...
  • Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Keysight Technologies shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3 Option YAS Installation Kit Option YAS Installation Kit Products Affected: MXE N9038A Serial Numbers: Options To Be Performed By: (X) Agilent Service Center (X) Personnel Qualified by Agilent (X) Customer Estimated Installation Time: 0.5 Hours Estimated Adjustment and Verification Time: 0.5 Hours...
  • Page 4 Option YAS Installation Kit Introduction This kit contains all of the instructions required to install Option YAS on the Agilent MXE EMI Receiver. Option YAS enables the ANALOG OUT port to provide a Y-Axis screen video output. The rear panel ANALOG OUT port is present on all MXE EMI Receivers, however Option YAS must be enabled via a license file.
  • Page 5 Option YAS Installation Kit Installation Procedure over USB 1. Locate the Option Upgrade Entitlement Certificate from the kit. 2. Redeem the Option Upgrade Entitlement Certificate by following the instructions on the Certificate. 3. After redeeming your Option Upgrade Entitlement Certificate you will receive an email with an attached License File.
  • Page 6 Option YAS Installation Kit 7. The signal analyzer will automatically consume the License File. (This may take a few minutes) When the License File is consumed the Agilent License Manager will display a “Successful License Installation” message as shown in Figure Figure 2 Successful License Installation...
  • Page 7 Option YAS Installation Kit Verify the Installation 1. Cycle the power on the signal analyzer. 2. Press System Show System to display a list of installed options. 3. Verify that the newly installed option appears on the list. Manually Verify Operation 1.
  • Page 8 Option YAS Installation Kit Utilities, Adjustments, and Performance Verification Tests Calibration Software and specified test equipment is required to perform the adjustments, and can be used to automate the performance verification testing. Information on how to obtain this software can be found at http://www.agilent.com/find/calibrationsoftware Utilities Required...
