Aerostat Sentry
Ionizing Blower
INSTALLATION AND OPERATING INSTRUCTIONS
AEROST AT S ENT RY
51 0 06 00 R ev. H

Advertisement

loading
Need help?

Need help?

Do you have a question about the Aerostat Sentry 4003000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Simco-Ion Aerostat Sentry 4003000

  • Page 1 Aerostat Sentry Ionizing Blower INSTALLATION AND OPERATING INSTRUCTIONS AEROST AT S ENT RY 51 0 06 00 R ev. H...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. DESCRIPTION ...................... 3 2. SAFETY ....................... 4 3. SPECIFICATIONS ....................5 4. INSTALLATION ....................7 5. OPERATION ......................8 6. MAINTENANCE ....................9 7. REPLACEMENT PARTS ..................10 8. WARRANTY ....................... 11 AEROST AT S ENT RY 51 0 06 00 R ev.
  • Page 3: Description

    1. DESCRIPTION The Sentry ionized air blower produces an airfl ow that is rich in positive and negative ions. Directing the airfl ow on an object that has a static charge will neutralize the charge. If the object has a positive static charge, it will draw negative ions from the airfl...
  • Page 4: Safety

    3. Inspect contents for damage that may have occurred during shipment. If any damage has occurred, the local carrier should be notified at once. A report should be forwarded to Simco-Ion, 2257 North Penn Road, Hatfield PA 19440, and (215) 822-6401.
  • Page 5: Specifications

    3. SPECIFICATIONS Unit Part Number: 4003000 4003143 Line Voltage: 115 VAC 230 VAC 60 Hz. 50 Hz Current Draw: Fan low 0.5 Amp 0.25 Amp Fan medium 0.7 Amp 0.35 Amp Fan high 0.9 Amp 0.45 Amp Air Volume Output: Fan Speed Flow 70 CFM...
  • Page 6 Enclosure: Steel Finish: Power Coated Weight: 17.5 lbs (7.9 kg) Size: 15 3/8” W x 4 1/2” H x 8 1/8 D (39.1 cm W x 11.4 cm H x 20.6 cm D) Bench Stand Feet: Nonconductive, nonstaining polymer Air Filter: 30 PPI open Cell Polyurethane Foam Aluminum Housing Ion Output (discharge time): Fan Speed –...
  • Page 7: Installation

    4. INSTALLATION Electrical Requirements The Sentry, P/N 4003000, requires 120VAC, 60 Hz for proper operation. The unit must be grounded for safe operation. Plug the unit into a standard 3-terminal grounded receptacle.’ The Sentry, P/N 4003143, requires 230VAC, 50 Hz for proper operation. The unit must be grounded for safe operation.
  • Page 8: Operation

    Placement Place the Sentry approximately 1 to 3 feet from the critical work area or objects to be neutralized. Position the ionized air stream to cover as much of the critical area as possible 1. Loosen lock knobs on sides of Sentry 2.
  • Page 9: Maintenance

    Ion Output Check A Simco-Ion fi eldmeter may be used to check the ion output using the following procedure: 1. Take a piece of plastic and rub it with a cloth until a static charge can be read with the fi...
  • Page 10 If no instrumentation is available, the unit’s operation can be verifi ed with the following procedure: Tear off about a 10 inch length of transparent tape. You will note that the tape is charged and will easily attract to a nearby surface, such as a wall, when held vertically approximately 1inch from the surface.
  • Page 11: Replacement Parts

    7. REPLACEMENT PARTS Part Number Description tem # 4670785 Handle 4500111 5050284 3-Speed Blower, 120 V 5050294 3-Speed Blower, 230 V 4630155 H.V. Transformer with Leads, 120 V 4630157 H.V. Transformer with Leads, 230 V 4104100 Ionizer Duct Assembly (includes ionizer & brush) 4670700 Brush 4401510...
  • Page 12: Warranty

    The equipment being returned under warranty should be shipped by the purchaser to Simco-Ion, 2257 North Penn Road, Hatfield PA 19440, transportation prepaid and insured for its replacement cost. Prior to returning any goods for any reason, contact Simco-Ion Customer Service at (215) 822-6401 for a Return Authorization Number. This number must accompany all returned items.

This manual is also suitable for:

Aerostat sentry 4003143
